Safety Switch E100-A2A22C05A | 2 N/C & 2 N/O Contacts | IP67 Rated | by SICK
The E100-A2A22C05A safety switch features 2 positive action normally closed (N/C) contacts and 2 normally open (N/O) contacts, ensuring reliable operation in industrial safety systems. With an IP67 rated enclosure, it protects against dust and water, making it ideal for machinery safety interlocks and automation applications. Designed for professional installation, this switch guarantees compliance with safety standards and offers a mechanical life of 100,000 switching cycles.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Positive action N/C contacts: 2
- N/O contacts: 2
- Actuation directions: 1
- B10d parameter: 5 x 10^5 switching cycles (small load)
- Safe state in event of fault: No internal fault detection; fault detection by connected safety logic unit
- Safe series connection: None, only individual wiring with diagnostics
- Connection type: Cable open end
- Cable length: 5 m
- Cable diameter: 8 mm
- Conductor cross section: 8 x 0.34 mm²
- Bend radius fixed installation: > 7.5 x cable diameter
- Bend radius moving cable: > 15 x cable diameter
- Cable material: PUR
- Conductor material: Copper
- Switching principle: Slow action switching element
- Usage category: AC-15/DC-13 (EN 60947-5-1)
- Rated operating current: 2 A (230 V AC), 2 A (24 V DC)
- Rated insulation voltage Ui: 250 V
- Rated impulse withstand voltage Uimp: 2,500 V
- Short-circuit protection: 2 A gG
- Switching voltage: ≥ 12 V DC
- Switching current (switching voltage): 1 mA (24 V DC)
- Mechanical life: 1 x 10^5 switching cycles
- Housing material: Plastic
- Enclosure rating: IP67 (EN 60529)
- Ambient operating temperature: –5 °C to +50 °C
- Storage temperature: –5 °C to +50 °C
- Dimensions (H x L x W): 132mm x 64mm x 64mm
- Weight: 1.32 kg
Key Features
- 2 positive action normally closed (N/C) contacts and 2 normally open (N/O) contacts
- Slow action switching element for reliable operation
- IP67 rated enclosure for protection against dust and water
- Cable open end connection with 5 m PUR cable and copper conductors
- Mechanical life of 100,000 switching cycles
- Rated operating current of 2 A at 230 V AC and 24 V DC
- Short-circuit protection with 2 A gG fuse
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with safety switch wiring and compliance with relevant safety standards.
Applications
- Industrial safety systems requiring reliable safety switch monitoring
- Machinery safety interlocks
- Automation and control systems with safety requirements
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Compliant with China-RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK E100-A2A22C05A safety switch is available for immediate purchase, ideal for industrial safety and automation applications.
