Safety Switch E100-A2A22S05A | 2 N/C & 2 N/O Contacts | IP67 Rated | by SICK
The E100-A2A22S05A safety switch features 2 positive action normally closed (N/C) contacts and 2 normally open (N/O) contacts, making it ideal for industrial safety systems and machinery safety interlocks. With an IP67 rated enclosure, it ensures reliable operation in harsh environments, while the slow action switching element guarantees safety in automation equipment circuits.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Positive action N/C contacts: 2
- N/O contacts: 2
- Actuation directions: 1
- B10d parameter: 5 x 10^5 switching cycles (small load)
- Safe state in event of fault: No internal fault detection; fault detection by connected safety logic unit
- Safe series connection: None, only individual wiring with diagnostics
- Connection type: Cable open end
- Cable length: 5 m
- Cable diameter: 8 mm
- Conductor cross section: 8 x 0.34 mm²
- Bend radius fixed installation: >7.5 x cable diameter
- Bend radius moving cable: >15 x cable diameter
- Cable material: PUR
- Conductor material: Copper
- Switching principle: Slow action switching element
- Usage category: AC-15/DC-13 (EN 60947-5-1)
- Rated operating current: 2 A (230 V AC), 2 A (24 V DC)
- Rated insulation voltage Ui: 250 V
- Rated impulse withstand voltage Uimp: 2,500 V
- Short-circuit protection: 2 A gG
- Switching voltage: ≥ 12 V DC
- Switching current (switching voltage): 1 mA (24 V DC)
- Mechanical life: 1 x 10^5 switching cycles
- Housing material: Plastic
- Enclosure rating: IP67 (EN 60529)
- Ambient operating temperature: –5 °C to +50 °C
- Storage temperature: –5 °C to +50 °C
- Dimensions (H x L x W): 132mm x 64mm x 64mm
- Weight: 0.86 kg
Key Features
- 2 positive action normally closed (N/C) contacts and 2 normally open (N/O) contacts
- Slow action switching element for reliable operation
- IP67 rated enclosure for protection against dust and water
- Cable open end connection with 5 m PUR cable and copper conductors
- Mechanical life of 100,000 switching cycles
- Rated operating current of 2 A at 230 V AC and 24 V DC
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with safety switch wiring and safety-related control systems.
Applications
- Industrial safety systems requiring reliable safety switch monitoring
- Machinery safety interlocks
- Automation equipment safety circuits
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Compliant with China-RoHS for restricted hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK for detailed warranty terms.
Available Now
The SICK E100-A2A22S05A safety switch is available for immediate purchase, ideal for industrial safety and automation applications.
