Safety Switch E100-B2A22S25A | 2 N/C & 2 N/O Contacts | IP65 Rated | by SICK
The E100-B2A22S25A safety switch is designed for industrial safety systems, featuring 2 positive action normally closed (N/C) contacts and 2 normally open (N/O) contacts. With a robust IP65 rated enclosure and a slow action switching element, it ensures reliable operation in automation and control systems. Ideal for machinery safety interlocks, this switch offers a mechanical life of 100,000 cycles, making it a durable choice for safety monitoring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Positive action N/C contacts: 2
- N/O contacts: 2
- Actuation directions: 1
- Switching principle: Slow action switching element
- Usage category: DC-13 (EN 60947-5-1)
- Rated operating current: 2 A (24 V DC), 100 mA (24 V DC)
- Rated insulation voltage Ui: 32 V
- Rated impulse withstand voltage Uimp: 800 V
- Short-circuit protection: 2 A gG / 0.1 A gG
- Switching voltage: ≥ 12 V DC
- Switching current: 1 mA (24 V DC)
- Cable length: 25 m
- Cable diameter: 9.8 mm
- Conductor cross section: 8 x 0.5 mm², 8 x 0.14 mm²
- Cable material: PUR
- Conductor material: Copper
- Enclosure rating: IP65 (EN 60529)
- Ambient operating temperature: –5 °C to +50 °C
- Mechanical life: 100,000 switching cycles
- Housing material: Plastic
- Dimensions (H x L x W): 132mm x 64mm x 64mm
- Weight: 1.32 kg
Key Features
- 2 positive action normally closed (N/C) contacts and 2 normally open (N/O) contacts
- Slow action switching element for reliable operation
- IP65 rated enclosure for protection against dust and water
- 25 meter PUR cable with copper conductors and flexible bend radius
- Mechanical life of 100,000 switching cycles
- Rated operating current of 2 A at 24 V DC
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with safety switch wiring and safety-related control systems.
Applications
- Industrial safety systems requiring reliable safety switch monitoring
- Machinery safety interlocks
- Automation and control systems with safety requirements
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Complies with China-RoHS for restricted hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK E100-B2A22S25A safety switch is available for immediate purchase, ideal for industrial safety and automation applications.
