sBot Speed CIP Software for FANUC R-30iB Plus | Automatic Restart & Speed Reduction | Safety Controller Included | by SICK
The sBot Speed CIP Software is designed for FANUC R-30iB Plus robot controllers, providing automatic restart with speed reduction and emergency stop features. Ideal for hazardous area protection in industrial robotic systems, this software enhances safety and efficiency, ensuring compliance with performance level PL d (ISO 13849-1). Perfect for automated manufacturing environments, it includes a programmable safety controller and comprehensive installation instructions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Variant: sBot Speed CIP
- Product type: Software
- Robot controller compatibility: FANUC R-30iB Plus
- Stopping process: Speed reduction
- Robot restart: Automatic
- Communication interface: EtherNet/IP™ CIP Safety™
- Safety controller type: Programmable
- Performance level: PL d (ISO 13849-1)
- Safety task: Hazardous area protection
- Items supplied: Software with Safety Designer project file, pre-configuration files, operating instructions, connection diagram, SISTEMA file
- Dimensions (H x L x W): 30mm x 150mm x 100mm
- Weight: 0.5 kg
Key Features
- Software variant: sBot Speed CIP
- Compatible with FANUC R-30iB Plus robot controller
- Emergency stop with shutdown and prevention of unexpected restart
- Automatic robot restart with speed reduction
- Safety-rated monitored speed triggering
- Operating mode selection and manual enabling device implemented in robot control
- Safety controller included and programmable
- Performance level PL d (ISO 13849-1)
- Communication interface: EtherNet/IP™ CIP Safety™
- Safe state outputs logic 0 in event of fault
Professional Installation Requirements
- Installation and configuration should be performed by qualified personnel familiar with FANUC robot controllers and safety software integration.
Applications
- Hazardous area protection in industrial robotic systems
- Safety control for FANUC R-30iB Plus robot controllers
- Emergency stop and safety speed monitoring in automated manufacturing
Standards & Compliance
- AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Enhances safety to reduce risk of accidents and associated environmental hazards
- Supports efficient robot operation reducing downtime and energy waste
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK for detailed warranty terms.
Available Now
The SICK SAPPC2D-08XS002 sBot Speed CIP software is available for immediate purchase, ideal for industrial automation safety applications.
