Screw Connection Terminal 10mm | 57A 1000V | DIN Rail Mount | Grey by NHP
Screw connection terminal with 10mm width and rated for 57A and 1000V—ideal for industrial and commercial electrical panels. Built for secure connections, with easy DIN rail mounting.
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 1492-J Screw Connection Terminal 10mm 1 Level 2 Conductor Entries Grey
Brand: NHP
SKU: 1492J10
Alternatively Known As: Screw Terminal Block, Feed-through Terminal Block
- Type of electrical connection: Screw connection
- Rated current: 57 A
- Rated voltage: 1000 V
- Number of levels: 1
- Number of clamp positions per level: 2
- Mounting method: DIN rail (top hat rail) 35 mm
- Nominal tightening torque: 2.3 Nm
- Wire conductor size: 0.5-10 mm
- Wire strip length: 12 mm
- Insulation temperature: -50-120 °C
- Dimensions (H x L x W): 60mm x 39.5mm x 10mm
- Weight: 0.1 kg
- Screw connection for secure electrical connections.
- Rated for 57 A and 1000 V for high-performance applications.
- DIN rail mounting for easy installation.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Industrial: Electrical panels, machinery, and control systems
- Commercial: Building automation and electrical installations
- Complies with relevant Australian electrical standards.
- Complies with UL94 V0 for safety and fire resistance.
1 year warranty against manufacturing defects.
The Allen-Bradley 1492-J Screw Connection Terminal is available now for immediate purchase. Ideal for industrial and commercial electrical applications.
