Sealable Terminal Shields for DPX3 160 Circuit Breaker | IP30 Rated | Enhanced Safety Features | @Each of 1 | by Legrand
Sealable terminal shields for DPX3 160 circuit breaker provide enhanced safety by preventing unauthorized access to terminals. Designed for electrical distribution panels and industrial switchboards, these shields are compatible with DPX³ 630 MCCBs and include fixing screws and insulated phase barriers. Ideal for qualified electricians to ensure compliance with safety standards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated permanent current: 400 A
- Rated voltage: 220-690 V
- Short-circuit breaking capacity Icu at 400 V, 50 Hz: 36 kA
- Overload release current setting: 160-400 A
- Adjustment range short-term delayed short-circuit release: 240-4000 A
- Adjustment range undelayed short-circuit release: 5000 A
- Device construction: Built-in fixed version
- Type of electrical connection: Screw connection
- Number of auxiliary contacts as change-over contact: 2
- With switched-off indicator and integrated under voltage release
- Number of poles: 3
- Degree of protection: IP30
- Contains non-rechargeable lithium batteries (CR1616)
- Dimensions (H x L x W): 100mm x 50mm x 150mm
- Weight: 1.5 kg
Key Features
- Sealable terminal shields designed for DPX3 160 circuit breaker 4 poles
- Compatible with DPX³ 630 - S2 electronic release MCCBs from 250 to 630 A
- Includes fixing screws, connection plates for bars, and insulated phase barriers
- Conforms to IEC 60947-2 standards
- Can be mounted on plate in XL³ cabinets and enclosures
- Provides enhanced safety by preventing unauthorized access to terminals
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with safety standards and proper integration with DPX3 circuit breakers.
Applications
- Electrical distribution panels
- Industrial and commercial switchboards
- Low voltage electrical line protection and control
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
- Enhances electrical safety reducing risk of faults and electrical hazards
- Supports compliance with safety standards reducing environmental risks from electrical failures
Warranty Information
Standard Legrand warranty applies, typically 1-2 years against manufacturing defects.
Available Now
Legrand Sealable Terminal Shields for DPX3 160 Circuit Breaker 4 Poles are available for immediate purchase, ideal for enhancing safety in electrical switchboards and power cabinets.
