Security Keypad Silver LCD to Suit D8X4G Ness
Ness silver LCD security keypad to Suit D8X4G. Ideal for alarm system installs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Ness KPX LCD Keypad Silver, Ness Silver LCD Alarm Keypad, Ness 106-015 Keypad
Technical Specifications
- Model: KPX LCD keypad, silver
- Part Number: 106-015
- Display: High-contrast LCD icon display with blue backlighting
- Operating Voltage: 13.8 VDC supplied by the control panel
- Compatibility: Ness D8X/D16X panels and D8XCEL4G/D16XCEL4G panels
- Data Connection: Four-wire proprietary Ness data bus
- Maximum Keypads: Up to three mixed keypads per compatible system
- Controls: Tactile keys with adjustable beep and chime volume
- Status Indication: Zone condition, armed state, mains, battery and alarm memory
- Dimensions (H x L x W): 135mm x 27mm x 90mm
- Weight: 0.2 kg
Key Features
- Silver finish for matching D8X4G security system installations
- High-contrast illuminated LCD icon display
- Displays system and zone status
- Backlit tactile buttons with hinged protective flap
- Adjustable LCD brightness and keypad beep volume
- Supports panic, fire and medical alarm key combinations on compatible panels
- Compatible with D8X4G panels, with no cellular status display on this keypad model
Professional Installation Requirements
- Installation and connection should be completed by a suitably qualified security alarm technician in accordance with the Ness installation documentation and applicable Australian requirements.
Applications
- D8X4G residential alarm system installations
- D8X4G commercial security alarm installations
- Replacement or additional keypad for compatible Ness D8X and D16X alarm panels
- Local arming, disarming and status monitoring of Ness alarm systems
Standards & Compliance
- AS/NZS 2201.1:2007 – relevant system-level standard for intruder alarm system design, installation, commissioning and maintenance; product-specific compliance is not stated by the manufacturer
Environmental Benefits
- Ness publishes RoHS compliance documentation for its product range
- Low-voltage operation supplied by the alarm control panel
- Durable electronic construction can reduce replacement frequency when correctly installed and maintained
Warranty Information
Ness manufactured or supplied products are covered by a 3-year warranty from the date of purchase, unless otherwise specified. Warranty claims are subject to Ness terms and conditions.
Available Now
Available through Ness and authorised Australian security and electrical distributors.
