Service Fuse 100A 22x58mm 80kA 415V VIC Bovara

BRAND: Bovara Electrical Equipment
SKU: ZR.2.100
$6.90 List price: $9.20
+ −
30 Days Return Electricians Unlock Trade Access
Bovara 100A service fuse link features 22 x 58mm body, 80kA breaking capacity at 415V AC to IEC 60269. Ideal for Victorian service fuse carriers.

Alternatively Known As: 100A Service Fuse, Victorian Service Fuse, 22 x 58mm Fuse Link, Cylindrical HRC Fuse Link

Technical Specifications
  • Rated Current: 100A
  • Rated Voltage: 415V AC
  • Breaking Capacity: 80kA
  • Fuse Body Size: 22 x 58mm
  • Fuse Type: Cylindrical service fuse link
  • Application Region: Victoria, Australia
  • Standard Reference: IEC 60269
  • Compatible Equipment: Victorian service fuse carriers
  • Manufacturer Item Number: ZR.2.100
  • Dimensions (H x L x W): 22mm x 58mm x 22mm
  • Weight: 0.1 kg
Key Features
  • 100A current rating for authority service protection applications
  • 22 x 58mm cylindrical fuse-link format
  • 80kA breaking capacity at 415V AC
  • Designed for compatible Victorian service fuse carriers
  • Replaceable fuse link allows continued use of the existing carrier
  • Suitable for service protection, fault current limiting and isolation applications
  • Includes a sealing facility in the Bovara ZR service fuse range
Professional Installation Requirements
  • Installation or replacement must be carried out by a licensed electrician or authorised electricity supply personnel. Isolate and verify the circuit before work and follow the applicable Victorian Service and Installation Rules and distribution network requirements.
Applications
  • Victorian electricity service fuse carriers
  • Authority service protection
  • Low-voltage electrical service entrances
  • Supply cable and line fault protection
  • Replacement of compatible 22 x 58mm service fuse links
  • Fault current limiting and isolation installations
Standards & Compliance
  • AS 60269.3.1-2005: relevant Australian standard reference for low-voltage fuse-links up to 100A and 500V; this edition is withdrawn and product-specific certification should be confirmed
Environmental Benefits
  • Passive protective device with no standby energy consumption
  • Replaceable fuse link allows the existing carrier to remain in service, reducing whole-component replacement waste
  • Long service life under correctly rated operating conditions can reduce replacement frequency
Warranty Information

No specific Bovara warranty period was located for this fuse link. Australian Consumer Law consumer guarantees apply where applicable; retain proof of purchase and contact the seller for product-specific warranty assistance.

Available Now

Available through authorised Bovara distributors in Australia.
