Service Fuse 20A 22x58mm 80kA 415V Bovara

BRAND: Bovara Electrical Equipment
SKU: ZR.2.20
$5.20 List price: $6.90
+ −
30 Days Return Electricians Unlock Trade Access
Bovara 20A service fuse link features 22 x 58mm body, 80kA breaking capacity at 415V AC to IEC 60269. Ideal for ZR2 service fuse carriers.

Alternatively Known As: 20A HRC Service Fuse, ZR2 Fuse Link, 22 x 58mm Cylindrical Fuse Link

Technical Specifications
  • Product Reference: ZR.2.20
  • Rated Current: 20A
  • Rated Voltage: 415V AC
  • Breaking Capacity: 80kA
  • Fuse Body Size: 22 x 58mm
  • Fuse Type: High-rupturing-capacity current-limiting cartridge fuse link
  • Standard Reference: IEC 60269
  • Pack Quantity: 1
  • Compatibility: Bovara ZR2 service fuse carriers
  • Dimensions (H x L x W): 22mm x 58mm x 22mm
  • Weight: 0.1 kg
Key Features
  • 80kA high fault-current breaking capacity at 415V AC
  • Compact 22 x 58mm cylindrical cartridge format
  • Designed for compatible Bovara ZR2 service fuse carriers
  • Suitable for authority service protection and meter protection equipment
  • Supports fault-current limiting and electrical isolation applications
  • Replaceable fuse-link design allows the carrier to remain in service
Professional Installation Requirements
  • Installation and replacement should be carried out by a licensed electrician or authorised electrical service provider with the supply isolated and verified dead. Service fuse equipment may be sealed or restricted by the electricity distributor; follow all local distributor requirements and use appropriate insulated tools and procedures.
Applications
  • Authority and utility service protection
  • Meter protection equipment
  • Bovara ZR2 service fuse carriers
  • Fault-current limiting in low-voltage electrical installations
  • Electrical distribution and isolation assemblies
Standards & Compliance
  • Manufacturer-stated compliance with IEC 60269 for low-voltage fuses
  • Relevant Australian requirements are covered by the AS/NZS 60269 series, including AS/NZS 60269.2.0 for fuses used by authorised persons; confirm the electricity distributor's exact service-fuse specification before installation
Environmental Benefits
  • Metal end caps and conductive components can generally be recovered through appropriate electrical-metal recycling streams
  • Replaceable fuse-link construction reduces the need to replace the complete carrier assembly
  • Long service life under correctly specified fault-protection conditions can reduce component waste
Warranty Information

No specific Bovara warranty period for this fuse link was publicly identified. Product claims are subject to applicable sale terms and Australian Consumer Law.

Available Now

Available through authorised Bovara distributors in Australia.
