Service Fuse 63A 22x58mm 80kA 415V Bovara

BRAND: Bovara Electrical Equipment
SKU: ZR.2.63
$5.20 List price: $6.90
+ −
30 Days Return Electricians Unlock Trade Access
Bovara 63A service fuse link features 22 x 58mm body, 80kA breaking capacity at 415V AC to IEC 60269. Ideal for ZR2 service fuse carriers.

Alternatively Known As: 63A Service Fuse, Authority Service Fuse Link, ZR2 Fuse Link, 22 x 58mm Fuse Cartridge

Technical Specifications
  • Manufacturer Part Number: ZR.2.63
  • Fuse Type: Cylindrical service fuse link
  • Rated Current: 63A
  • Rated Voltage: 415V AC
  • Breaking Capacity: 80kA
  • Fuse Body Size: 22 x 58mm
  • Standard: IEC 60269
  • Carrier Compatibility: Bovara ZR2 service fuse carriers
  • Application Category: Authority service protection and fault-current limitation
  • Dimensions (H x L x W): 22mm x 58mm x 22mm
  • Weight: 0.1 kg
Key Features
  • 63A rating for electrical service protection applications
  • 80kA high fault-current breaking capacity at 415V AC
  • Compact 22 x 58mm cylindrical fuse-link format
  • Designed for Bovara ZR2 service fuse carriers
  • Suitable for authorised service and isolation applications
Professional Installation Requirements
  • Installation and replacement must be carried out by the electricity supply authority, an authorised person or a suitably licensed electrician in accordance with applicable service rules and electrical installation requirements. De-energise and isolate the circuit before handling.
Applications
  • Authority service fuse carriers
  • Electrical service entrance protection
  • Low-voltage distribution equipment
  • Fault-current limitation
  • Replacement of compatible Bovara ZR2 fuse links
Standards & Compliance
  • IEC 60269 low-voltage fuse requirements
  • AS 60269.1 general requirements for low-voltage fuses
  • AS 60269.2.1 supplementary requirements for fuse systems used by authorised persons
Environmental Benefits
  • Metal fuse components can be recovered through appropriate electrical waste recycling streams
  • Provides durable overcurrent protection that can help reduce damage to downstream electrical equipment and replacement waste
  • Replaceable fuse-link design allows the carrier assembly to remain in service when only the link has operated
Warranty Information

Bovara-specific warranty terms are not publicly specified. Australian Consumer Law statutory consumer guarantees apply where applicable.

Available Now

Available through authorised Bovara distributors in Australia.
