Service Fuse 80A 22x58mm 80kA 415V Bovara

BRAND: Bovara Electrical Equipment
SKU: ZR.2.80
$6.90 List price: $9.20
+ −
30 Days Return Electricians Unlock Trade Access
Bovara 80A service fuse link features 22 x 58mm body, 80kA breaking capacity at 415V AC to IEC 60269. Ideal for ZR2 service fuse carriers.

Alternatively Known As: 80A HRC Service Fuse, ZR2 Service Fuse Link, Cylindrical Fuse Link, 22 x 58 mm Fuse

Technical Specifications
  • Product Reference: ZR.2.80
  • Rated Current: 80 A
  • Rated Voltage: 415 V AC
  • Breaking Capacity: 80 kA
  • Fuse Body Size: 22 x 58 mm
  • Fuse Type: High-rupturing-capacity current-limiting cartridge fuse link
  • Fuse Body: Cylindrical cartridge type
  • Compatibility: Bovara ZR2 service fuse carriers
  • Standard Reference: IEC 60269
  • Pack Quantity: 1
  • Dimensions (H x L x W): 22mm x 58mm x 22mm
  • Weight: 0.1 kg
Key Features
  • 80 A rating for service protection applications
  • 80 kA breaking capacity at 415 V AC
  • Compact 22 x 58 mm cylindrical fuse-link format
  • Designed for compatible Bovara ZR2 service fuse carriers
  • Suitable for authority service protection, fault-current limitation and isolation assemblies
  • Current-limiting protection helps reduce fault damage to downstream equipment
Professional Installation Requirements
  • Installation and replacement should be performed by a licensed electrician or authorised electricity-distributor service provider using appropriate insulated tools and procedures. Sealed service-fuse equipment must not be accessed without the required authority.
Applications
  • Authority service protection equipment
  • Meter protection assemblies
  • Fault-current-limiting applications
  • Electrical isolation assemblies
  • Replacement fuse links for compatible Bovara ZR2 service fuse carriers
Standards & Compliance
  • IEC 60269, as specified for the product
  • Australian low-voltage fuse requirements have historically been covered by AS 60269.1 and AS 60269.3.1; verify the applicable current electricity-distributor and installation requirements before use
Environmental Benefits
  • Metal fuse components may be recyclable through suitable electrical or metal recycling facilities
  • Durable ceramic and metal construction can extend service life and reduce replacement waste
  • Current-limiting fault protection can help prevent damage to downstream electrical equipment and associated material waste
Warranty Information

No specific Bovara manufacturer warranty period was located for this fuse link; refer to supplier terms and applicable Australian statutory consumer guarantees.

Available Now

Available through authorised Bovara distributors in Australia.
