Set of Sliding Nuts | Through-Beam Photoelectric Sensor | IP67 & IP69K Rated | Easy Installation | by SICK
The Set of Sliding Nuts is designed for through-beam photoelectric sensors, featuring a sensing range of up to 80 m and a visible red laser light source at 650 nm. Ideal for industrial automation and high-speed object detection, this set includes a mounting bracket for easy installation and boasts an IP67 and IP69K rating for superior protection against dust and water.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Sliding Nut Set, Photoelectric Sensor Mounting Nuts, Sensor Mounting Bracket Set
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range max.: 0 m to 80 m
- Light source: Laser, visible red light, wavelength 650 nm
- Light spot size: Ø 150 mm at 60 m
- Laser class: 2
- Supply voltage: 10 V DC to 30 V DC
- Current consumption sender: ≤ 45 mA
- Current consumption receiver: ≤ 15 mA
- Protection class: III
- Digital output type: PNP
- Switching frequency: 2,500 Hz
- Response time: ≤ 200 µs
- Housing material: Metal
- Front screen material: Plastic, PMMA
- Connection: Male connector M12, 4-pin
- Enclosure rating: IP67, IP69K
- Operating temperature: –10 °C to +50 °C
- Storage temperature: –25 °C to +75 °C
- Dimensions (H x L x W): 49mm x 41.5mm x 15mm
- Weight: 0.26 kg
Key Features
- Through-beam photoelectric sensor with a sensing range up to 80 m
- Visible red laser light source with 650 nm wavelength
- Light spot size Ø 150 mm at 60 m distance
- Includes mounting bracket BEF-WN-W12 for easy installation
- Metal housing with plastic PMMA front screen
- IP67 and IP69K rated for protection against dust and water
- Operating temperature range from –10 °C to +50 °C
- High switching frequency of 2,500 Hz and fast response time ≤ 200 µs
- Selectable switching mode via L/D control cable
- Digital PNP output with max output current ≤ 100 mA
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper sensor alignment and secure mounting using the supplied bracket.
Applications
- Industrial automation for object detection
- High-speed object detection
- Mounting on mirror column PM3S13-S02
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Durable metal housing and high protection rating reduce replacement frequency and waste
- Energy-efficient laser sensor technology minimizes power consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK Set of Sliding Nuts is available for immediate purchase, ideal for industrial automation and sensor mounting applications.
