Short Range RFID Reader | Integrated Antenna | HF Frequency 13.56 MHz | IP67 Rated | by SICK
The Short Range RFID Reader RFH510-1004301 is designed for efficient RFID identification in industrial automation. With an integrated antenna and a read range of up to 60 mm, it operates at a frequency of 13.56 MHz and supports ISO/IEC 15693 standards. Its robust brass housing and IP67 rating ensure durability in harsh environments, making it ideal for asset tracking and process control applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Version: Short Range
- Product category: RFID read/write device with integrated antenna
- Radio approval: European Union, USA, Canada, Australia, Korea, México, China, India, United Kingdom, Singapore
- Frequency band: HF (13.56 MHz)
- Carrier frequency: 13.56 MHz
- RFID standard: ISO/IEC 15693, ISO/IEC 18000-3 Mode 1
- Connection type: IO-Link
- Read range: ≤ 60 mm
- Antenna: Integrated
- Air interface data transmission rate: 26 kbit/s
- Connection type: 1 x M12, 4-pin male connector
- Supply voltage: 11 V DC to 32 V DC
- Power consumption: ≤ 1.8 W
- Housing material: Brass (chromium-plated) PBTP (blue)
- Enclosure rating: IP67
- Protection class: II
- Weight: 87 g including nuts
- Design: Cylindrical (M30)
- MTTF: > 756 years
- IO-Link version: V1.1
- Process data length: IN 32 bytes, OUT 32 bytes
- Data transmission rate: COM3 (230.4 kBaud)
- Digital outputs: 1 (Q2, Switching, PNP, IO-Link mode), 2 (Q1, Q2, Switching, PNP, SIO mode)
- Optical indicators: 4 LEDs, multi-color
- Configuration software: PLC software SOPAS ET
- Electromagnetic compatibility: EN 301489-3 V1.6.1 (2013)
- Vibration resistance: IEC 60068-2-6:2007-12 (10 Hz to 55 Hz / 1 min / 5 min)
- Shock resistance: IEC 60068-2-27:2008-02 (30 gn / 11 ms / half-sine)
- Ambient operating temperature: -25 °C to +80 °C
- Storage temperature: -25 °C to +80 °C
- Permissible relative humidity: 0% to 95%, non-condensing
- Dimensions (H x L x W): 30mm x 30mm x 30mm
- Weight: 0.1 kg
Key Features
- Short range RFID read/write device with integrated antenna
- Operates at HF frequency band (13.56 MHz)
- Supports ISO/IEC 15693 and ISO/IEC 18000-3 Mode 1 RFID standards
- Connection via IO-Link with 1 x M12, 4-pin male connector
- Read range up to 60 mm
- Robust brass chromium-plated housing with PBTP blue material
- IP67 rated enclosure for dust and water protection
- Wide operating temperature range from -25°C to +80°C
- Low power consumption ≤ 1.8 W
- Multi-color LED indicators for process feedback
- High mean time to failure (MTTF) greater than 756 years
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with IO-Link devices and industrial electrical standards to ensure proper integration and safety.
Applications
- Industrial automation for short-range RFID identification
- Process control and monitoring
- Asset tracking in manufacturing environments
- Integration with IO-Link enabled systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption reduces energy usage
- Durable housing extends product lifespan, reducing waste
- Complies with RoHS regulations limiting hazardous substances
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK RFH510-1004301 RFID read/write device is available for immediate purchase, ideal for industrial automation and asset tracking applications requiring short-range RFID identification.
