Shunt Releases for DPX3 160/250 Circuit Breaker | 400 VA/W Power | 400 A Current Rating | 70 kA Short-Circuit Capacity | @EA of 1 | by Legrand
Shunt releases for DPX3 160/250 circuit breaker provide a maximum power rating of 400 VA/W and a rated permanent current of 400 A, making them ideal for electrical distribution panels and industrial power management. With a short-circuit breaking capacity of 70 kA at 400 V, these devices ensure enhanced safety and efficient power management in commercial and residential switchboards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Shunt Releases for DPX3 160/250 Circuit Breaker | 400 VA/W Power | 400 A Current Rating | 70 kA Short-Circuit Capacity | @EA of 1 | by Legrand
Brand: Legrand
SKU: 422035
Alternatively Known As: DPX3 Shunt Release, Circuit Breaker Shunt Release, Legrand DPX3 Release Module
Technical Specifications
- Maximum power: 400 VA/W
- Rated permanent current (Iu): 400 A
- Rated voltage: 220-690 V
- Short-circuit breaking capacity (Icu) at 400 V, 50 Hz: 70 kA
- Overload release current setting: 320-400 A
- Adjustment range undelayed short-circuit release: 2000-4000 A
- Device construction: Built-in fixed built-in technique
- Integrated earth fault protection: No
- Type of electrical connection: Screw connection
- Suitable for DIN rail mounting: No
- Number of auxiliary contacts as change-over contact: 2
- Switched-off indicator: Yes
- Integrated under voltage release: Yes
- Number of poles: 4
- Position of connection for main current circuit: Front side
- Type of control element: Wing knob
- Complete device with protection unit: Yes
- Motor drive integrated: No
- Motor drive optional: Yes
- Degree of protection (IP): IP30
- Dimensions (H x L x W): 150mm x 120mm x 100mm
- Weight: 2.5 kg
Key Features
- Maximum power rating of 400 VA/W
- Rated permanent current of 400 A
- Rated voltage range from 220 to 690 V
- Short-circuit breaking capacity of 70 kA at 400 V, 50 Hz
- Overload release current setting adjustable between 320-400 A
- Undelayed short-circuit release adjustable from 2000-4000 A
- Built-in fixed device construction
- Two auxiliary change-over contacts
- Switched-off indicator included
- Integrated under voltage release
- Front side connection for main current circuit
- Wing knob type control element
- Complete device with protection unit
- IP30 degree of protection
Professional Installation Requirements
- Installation must be performed by a qualified electrician to ensure compliance with electrical safety standards and proper integration into switchboard systems.
Applications
- Electrical distribution panels
- Industrial power management
- Commercial and residential switchboards
- Modular switch and circuit breaker systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances electrical safety reducing risk of faults and electrical fires
- Supports efficient power management reducing energy waste
Warranty Information
Standard manufacturer warranty of 2 years against defects.
Available Now
Legrand Shunt Releases for DPX3 160/250 Circuit Breaker are available for immediate purchase, ideal for use in modular switchboards and power cabinets in commercial and industrial applications.
