Shunt Releases for DPX3 160/250 Circuit Breaker | 400 VA Power | 500 A Rated Current | IP30 Protection | @Each of 1 | by Legrand
Shunt releases for DPX3 160/250 circuit breaker provide a maximum power rating of 400 VA and a rated permanent current of 500 A, making them ideal for industrial and commercial electrical distribution. With a short-circuit breaking capacity of 70 kA at 400 V, these devices ensure enhanced safety and reliability in power distribution applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Shunt Releases for DPX3 160/250 Circuit Breaker | 400 VA Power | 500 A Rated Current | IP30 Protection | @Each of 1 | by Legrand
Brand: Legrand
SKU: 422036
Alternatively Known As: DPX3 Shunt Release, Circuit Breaker Shunt Release, Legrand DPX3 Release Module
Technical Specifications
- Maximum power: 400 VA/W
- Rated permanent current (Iu): 500 A
- Rated voltage: 220-690 V
- Short-circuit breaking capacity (Icu) at 400 V, 50 Hz: 70 kA
- Overload release current setting: 400-500 A
- Undelayed short-circuit release adjustment range: 2500-5000 A
- Device construction: Built-in fixed device
- Integrated earth fault protection: No
- Main circuit electrical connection: Screw connection
- Suitable for DIN rail mounting: No
- Number of auxiliary contacts (change-over): 2
- Switched-off indicator: Yes
- Integrated under voltage release: Yes
- Number of poles: 4
- Connection position for main current circuit: Front side
- Control element type: Wing knob
- Complete device with protection unit: Yes
- Motor drive integrated: No
- Motor drive optional: Yes
- Degree of protection (IP): IP30
- Dimensions (H x L x W): 150mm x 120mm x 100mm
- Weight: 3.5 kg
