Single Connector Terminal 40A | 500V AC Rated | Screw Clamp Connection | by Clipsal
The Single Connector Terminal 40A is designed for secure high-current cable connections, rated for 40A and 500V AC. Ideal for residential and commercial electrical installations, this single pole connector features a robust screw clamp mechanism for reliable performance with copper conductors. Perfect for use in electrical distribution boards and industrial control panels.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Single Connector Terminal 40A | 500V AC Rated | Screw Clamp Connection | by Clipsal
Brand: Clipsal
SKU: CLI563B/100
Alternatively Known As: 40A Terminal Block, Single Pole Connector, Electrical Terminal 40A, Clipsal Terminal Block, CLI563B/100
Technical Specifications
- Current Rating: 40A
- Voltage Rating: 500V AC
- Number of Poles: 1
- Conductor Material: Copper
- Body Material: Flame-retardant plastic
- Connection Type: Screw clamp
- Cable Capacity: 2.5mm² to 10mm²
- Dimensions (H x L x W): 20mm x 35mm x 15mm
- Weight: 0.1 kg
Key Features
- Rated for 40A high current applications
- Single pole terminal for secure cable connection
- Robust construction for reliable performance
- Suitable for copper conductors
- Screw clamp mechanism ensures strong electrical contact
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Residential: Electrical distribution boards, switchboards
- Commercial: Industrial control panels, machinery wiring
- General: Any application requiring secure high-current cable termination
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Supports safe and efficient electrical connections, minimizing energy loss
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Single Connector Terminal 40A CLI563B/100 is available for immediate purchase. Ideal for secure high-current cable connections in residential, commercial, and industrial electrical installations.
