Single Mode Fibre Optic Pigtails | 12 Fibres | 9µm Core & LSZH Buffer by Cabac
MSS Fibre SM 9um 12-Fibre LC 900um Pigtails - 12 Pack by Cabac offers high-performance OS2 fibre optic pigtails with LSZH tight buffer, ideal for telecommunications and data communication applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: MSS Fibre SM 9um 12-Fibre LC 900um Pigtails - 12 Pack
Brand: Cabac
SKU: PLC2M/900-SMC12
Alternatively Known As: Single Mode Fibre Optic Pigtails, LC 12-Fibre Pigtails, OS2 Fibre Pigtails, LSZH Fibre Pigtails
Technical Specifications
- Fibre Type: Single Mode OS2
- Core Diameter: 9 µm
- Fibre Count: 12 fibres
- Connector Type: LC UPC
- Buffer Diameter: 900 µm
- Standards Compliance: ITU-T G652.D, TIA/EIA 492 CAAB
- Fibre Colour Coding: IEC 60304, TIA-598
- Material Compliance: REACH, RoHS, SvHC
- Dimensions (H x L x W): 100mm x 10mm x 150mm
- Weight: 0.05 kg
Key Features
- 6 or 12 Pack UPC Connector Pigtails packaged and labelled for protection, performance data, and traceability
- 900um Low Smoke Zero Halogen (LSZH) tight buffer
- OS2 fibre conforms to ITU-T G652.D, TIA/EIA 492 CAAB standards
- Individual fibres coloured as per IEC 60304, TIA-598
- REACH, RoHS and SvHC materials compliant
Professional Installation Requirements
- Installation by a qualified fibre optic technician is recommended to ensure optimal performance and compliance with standards.
Applications
- Telecommunications networks
- Data centers and server rooms
- Fibre optic communication systems
- FTTx (Fiber to the x) installations
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low Smoke Zero Halogen (LSZH) materials reduce toxic emissions in case of fire
- Compliant with REACH, RoHS, and SvHC standards ensuring environmentally safe materials
Warranty Information
Standard manufacturer warranty applies, typically 1 year against defects.
Available Now
The MSS Fibre SM 9um 12-Fibre LC 900um Pigtails - 12 Pack by Cabac is available now for immediate purchase. Ideal for telecommunications and data communication network installations.
