Single Phase KWH Meter 63A Pulse | LCD Display | DIN Rail Mount | Pulse Output for Remote Monitoring | @Quantity of 1 | by Clipsal
The Single Phase KWH Meter 63A Pulse is designed for accurate energy monitoring in residential, commercial, and industrial applications. With a maximum current rating of 63A, an LCD display for easy reading, and pulse output for remote monitoring, this meter is perfect for energy management systems. Its compact DIN rail mount design ensures straightforward installation, making it an essential tool for efficient energy usage.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Single Phase KWH Meter 63A Pulse | LCD Display | DIN Rail Mount | Pulse Output for Remote Monitoring | @Quantity of 1 | by Clipsal
Brand: Clipsal
SKU: SCHA9MEM2105
Alternatively Known As: Single Phase Energy Meter, 63A KWH Meter, DIN Rail Power Meter, Clipsal SCHA9MEM2105, Pulse Output Energy Meter
Technical Specifications
- Rated Voltage: 230V AC
- Current Rating: 63A
- Frequency: 50Hz
- Pulse Output: Yes (for remote monitoring)
- Display: LCD
- Mounting: DIN rail
- Accuracy Class: Class 1
- Operating Temperature: -25°C to +55°C
- Dimensions (H x L x W): 90mm x 65mm x 36mm
- Weight: 0.3 kg
Key Features
- 63A maximum current rating for single phase applications
- Pulse output for remote monitoring and integration with energy management systems
- LCD display for clear and easy reading of energy usage
- Compact DIN rail mount design for easy installation
- High accuracy class for reliable energy measurement
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with Australian standards.
Applications
- Residential: Monitoring household energy consumption
- Commercial: Office and retail energy metering
- Industrial: Sub-metering for equipment and machinery
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables precise energy monitoring to support energy-saving initiatives
- Facilitates identification of high-consumption areas for targeted efficiency improvements
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Single Phase KWH Meter 63A Pulse SCHA9MEM2105 is available for immediate purchase. Ideal for accurate energy monitoring in residential, commercial, and industrial settings.
