Single Screw Connectors 32Amp | PVC Insulated & Brass Connections | Clear Housing | 100 Pcs Jar by Cabac
Heavy-duty insulated screw connectors by Cabac, rated 32Amp for 240/415V applications, accommodating up to 2 x 6mm² cables, supplied in a 100 piece screw top jar for easy use in electrical wiring.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Single Screw Connect 32Amp 100Pcs Jar
Brand: Cabac
SKU: HICSS-100
Alternatively Known As: Insulated Screw Connectors, Electrical Screw Connectors, 32A Screw Terminal Connectors, PVC Insulated Connectors
Technical Specifications
- Material Body: PVC
- Connections: Brass
- Nominal Ratings Voltage: 240/415V
- Amperage: 32A
- Accommodates maximum 2 x 6mm² cables
- Available in one and two screw formats (two screw for earth)
- Dimensions (H x L x W): 100mm x 100mm x 100mm
- Weight: 0.2 kg
Key Features
- Clear plastic housing allows visual inspection of termination
- Soft plastic housing with no sharp edges for user comfort
- Nominal 32A rating, dependent on conductor loading
- Rated for normal 240/415V applications
- Supplied in handy screw top jars
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards.
Applications
- Used by electricians in junction boxes for general connections
- Connecting light fittings
- General purpose wiring connections
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce the need for frequent replacements
- Clear housing enables proper installation reducing electrical faults and waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms.
Available Now
The Cabac Single Screw Connect 32Amp Insulated Screw Connectors 100Pcs Jar is available now for immediate purchase. Ideal for electrical wiring and general purpose connections.
