Slim Line Relay 8A 2 CO DPDT | 12V DC Coil | LED Indication by NHP
Slim line relay with 8A nominal current and 12V DC coil—ideal for industrial automation and control panels. Built for reliable switching, with LED indication and easy plug-in installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 700-HK General Purpose Slim Line Relay 8A 2 CO DPDT 12V DC Coil with Pilot Light
Brand: NHP
SKU: 700HK32Z124
Alternatively Known As: Slim Line Relay, General Purpose Relay, DPDT Relay
Technical Specifications
- Nominal Current: 8 A
- Nominal Voltage AC: 250 V
- Rated Switching Power at AC-1: 2000 VA
- Rated Switching Power at AC-15 (230 V): 350 VA
- Breaking Capacity at DC-1 (30 V): 6 A
- Control Supply Voltage: 12 V DC
- Electrical Life: 30,000 cycles
- Mechanical Life: 10,000,000 cycles
- Material Contact: Silver nickel
- Degree of Protection: IP20
- Operating Temperature: -40 to 70 °C
- Dimensions (H x L x W): 29mm x 32.8mm x 12.4mm
- Weight: 0.1 kg
Key Features
- General purpose relay with 8A nominal current.
- 12V DC coil with LED indication.
- Plug-in connection for easy installation.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring reliable switching
Standards & Compliance
- Complies with relevant Australian standards for electrical safety.
Environmental Benefits
- Energy-efficient design reduces power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 700-HK General Purpose Slim Line Relay is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable switching.
Non-Returnable & Non-Cancellable
