Slim Relay 1C/O 6A 48 VDC | Space-Saving 6mm Width | LED Indicator | by Clipsal
The Slim Relay 1C/O 6A 48 VDC is designed for efficient space-saving installations, featuring a compact 6mm width and a reliable 6A contact rating. Ideal for industrial automation and control panels, this relay ensures high electrical endurance and includes an LED indicator for coil status, making it perfect for building management systems and general electrical switching applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Slim Relay 1C/O 6A 48 VDC | Space-Saving 6mm Width | LED Indicator | by Clipsal
Brand: Clipsal
SKU: SCHRSL1AB4ED
Alternatively Known As: Slim Interface Relay, RSL1AB4ED, 6A 48VDC Slim Relay, Clipsal Industrial Relay, Schneider Slim Relay
Technical Specifications
- Contact configuration: 1 C/O (SPDT)
- Contact rating: 6A at 250VAC/30VDC
- Coil voltage: 48 VDC
- Coil consumption: 0.53 W
- Dielectric strength: 4000 V AC (between coil and contacts)
- Mechanical endurance: 10,000,000 operations
- Electrical endurance: 100,000 operations at rated load
- Operating temperature: -40°C to +70°C
- LED indicator: Yes
- Mounting: DIN rail
- Terminal type: Screw
- Dimensions (H x L x W): 80mm x 78mm x 6mm
- Weight: 0.1 kg
Key Features
- Slim 6 mm width for space-saving installation
- 1 changeover (C/O) contact rated at 6A
- 48 VDC coil voltage
- Plug-in relay for easy replacement
- LED indicator for coil status
- Finger-safe terminals for enhanced safety
- High electrical endurance
Professional Installation Requirements
- Installation by a qualified electrician is required to ensure compliance with electrical safety standards.
Applications
- Industrial automation panels
- Building management systems
- Control cabinets
- Switchboards
- General electrical switching applications
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Compact design reduces material usage and panel space
- Low power consumption coil
- Long operational life reduces waste
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal Slim Relay 1C/O 6A 48 VDC (SCHRSL1AB4ED) is available for immediate purchase. Ideal for industrial automation, control panels, and building management systems.
