SmartSense SmartHub App Gateway for Wireless Family Alarms Cavius

BRAND: Cavius
SKU: 02200
$147.80 List price: $197.10
+ −
30 Days Return Electricians Unlock Trade Access
Cavius SmartSense SmartHub. Plugs into your router, connects Wireless Family alarms to the Cavius app for alerts, tests and low battery notices.

Alternatively Known As: Cavius 02200, SmartSense SmartHub, Cavius Wireless Family SmartHub

Technical Specifications
  • Product Code: 02200
  • Product Type: SmartHub and app gateway
  • Power: 5V DC 1A Micro USB
  • Input Voltage: 5V DC 1A
  • Output Voltage: 5V DC 0.5A
  • Connection: RJ45 Ethernet
  • RF Frequency: 918.65 MHz and 926.365 MHz
  • RF Range: Up to 100m
  • Dimensions: 140 x 80 x 29mm
  • Weight: 100g
  • Colour: White
  • Certification: RCM, CE
  • Dimensions (H x L x W): 29mm x 140mm x 80mm
  • Weight: 0.1 kg
Key Features
  • Connects Cavius Wireless Family devices to the Cavius app
  • Sends smartphone notifications when an alarm activates
  • Identifies which alarm has activated
  • Provides low battery notifications
  • Provides connection status notifications
  • Allows alarm testing through the app
  • Supports fire drill testing
  • Supports multiple users and properties
  • Connects through a router using Ethernet
Professional Installation Requirements
  • Connect the SmartHub to a compatible router and power supply according to the manufacturer's instructions.
Applications
  • Smart home fire safety
  • Remote smoke alarm monitoring
  • Remote heat alarm monitoring
  • Rental property monitoring
  • Multiple-property alarm monitoring
  • Wireless Family alarm systems
Standards & Compliance
  • RCM certified.
  • CE certified.
Environmental Benefits
  • Enables remote monitoring and testing of connected alarms
  • Supports long-term monitoring without requiring replacement of existing Wireless Family alarms
Warranty Information

Warranty information should be confirmed with Cavius Australia or the authorised distributor.

Available Now

Available from Cavius Australia and authorised distributors.

Smoke Alarm Placement Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
