Soldersleeve Yellow 2.0-6.0mm² | Sealed Solder Joint | Vibration Resistant | Heatshrink by Cabac
Cabac Soldersleeve Yellow 2.0-6.0mm² is an adhesive lined heatshrink tube with low melt point fluxed solder sleeve, providing sealed, vibration-resistant electrical splices ideal for hostile or moist environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Soldersleeve Yellow 2.0 -6.0mm2
Brand: Cabac
SKU: SSYL-X
Alternatively Known As: Heatshrink Solder Splice, Solder Sleeve Connector, Heat Shrink Solder Sleeve, Electrical Solder Splice Tube
Technical Specifications
- Melting temperature: 126 to 145°C
- Temperature rating: -55 to +95°C
- Dielectric strength: 15 kV/mm
- Insulation resistance: 10¹⁴ Meg Ohms
- Mil Spec of Tubing: MIL-I-23053/4, Class 1 AMS-3634
- Mil Spec of Solder: QQ5571E, MIL-S-14256
- Dimensions (H x L x W): 10mm x 100mm x 30mm
- Weight: 0.01 kg
Key Features
- Completely sealed soldered joint created in one go
- Heatshrink with internal glue liner melts and seals the joint
- Provides good strain relief and high vibration resistance
- Fast and efficient way of joining two conductors
- Ideal for connections in hostile or moist environments
Professional Installation Requirements
- Installation should be performed by a qualified electrician or trained professional using a heat gun set to approximately 250°C. Avoid open flames to prevent damage.
Applications
- Electrical wiring connections requiring sealed and vibration-resistant joints
- Connections in hostile or moist environments
- Automotive, marine, and industrial electrical splicing
- General electrical and power connectivity applications
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Reduces need for additional connectors and materials by providing a one-step solder and seal solution
- Durable sealed joints reduce risk of corrosion and electrical failure, extending product lifespan
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.
Available Now
The Cabac Soldersleeve Yellow 2.0-6.0mm² is available for immediate purchase. Ideal for electrical splicing in residential, commercial, and industrial applications.
