Solid State Relay 50A | Zero Voltage Switching | Panel Mount | 18-36V AC Input by Clipsal
Solid state relay with 50A capacity and zero voltage switching—ideal for industrial automation and commercial HVAC systems. Built for reliable operation, with panel mount design and wide input voltage range.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Harmony Solid State Relays, Solid state relay, 50A, panel mount, zero voltage switching, input 18…36V AC, output 48…530V AC
Brand: Clipsal
SKU: SSP3A250B7
Alternatively Known As: Solid State Relay, SSR, 50A Relay, Panel Mount Relay
Technical Specifications
- Rated current: 50 A
- Control circuit voltage: 18-36 V AC
- Output voltage: 48-530 V AC
- Insulation resistance: >= 1000 MOhm at 500 V DC
- IP degree of protection: IP20
- Response time: 20 ms (turn-on), 30 ms (turn-off)
- Surge current: 715 A for 20 ms
- Maximum leakage current: 3 mA off-state
- Maximum voltage drop: <1.35 V on-state
- Flame retardance: V0 conforming to UL 94
- Dimensions (H x L x W): 80mm x 35mm x 101mm
- Weight: 0.24 kg
Key Features
- Zero voltage switching for reliable operation.
- Panel mount design for easy installation.
- Wide input voltage range of 18-36V AC.
- Output voltage range of 48-530V AC.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial: Automation systems, machinery control
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with IEC 61000, IEC 60950-1, IEC 62314
Environmental Benefits
- Packaging made with recycled cardboard.
- No single-use plastic in packaging.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Clipsal Harmony Solid State Relay 50A is available now for immediate purchase. Ideal for industrial and commercial applications.
