Solid State Relay 50A | Zero Voltage Switching | Panel Mount | Thermal Pad by Clipsal
Solid state relay with 50A capacity and zero voltage switching—ideal for industrial automation and control. Built for reliable operation, with panel mount design and thermal pad for efficient heat dissipation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Harmony Solid State Relays, Solid state relay, 50A, panel mount, zero voltage switching, thermal pad, input 18…36V AC, output 48…530V AC
Brand: Clipsal
SKU: SSP3A250B7T
Alternatively Known As: Solid State Relay, SSR, Panel Mount Relay, 50A Relay
Technical Specifications
- Rated current: 50 A
- Control circuit voltage: 18...36 V AC
- Output voltage: 48...530 V AC
- Insulation resistance: >= 1000 MOhm at 500 V DC
- IP Rating: IP20
- Response time: 20 ms (turn-on), 30 ms (turn-off)
- Surge current: 715 A for 20 ms
- Maximum leakage current: 3 mA off-state
- Dielectric strength: 4 kV AC for input/output
- Dimensions (H x L x W): 74.6mm x 41mm x 104mm
- Weight: 0.37 kg
Key Features
- Zero voltage switching for reliable operation.
- Panel mount design for easy installation.
- Thermal pad included for efficient heat dissipation.
- LED indicator for input status.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial: Automation systems, machinery control
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with IEC/EN 62314 and IEC/EN 60947 standards.
Environmental Benefits
- Packaging made with recycled cardboard.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Clipsal Harmony Solid State Relay 50A is available now for immediate purchase. Ideal for industrial automation and control applications.
