Solid State Relay 50A | Zero Voltage Switching | Panel Mount | Thermal Pad by Clipsal
Solid state relay with 50A capacity and zero voltage switching—ideal for industrial automation and commercial HVAC systems. Built for efficient operation, with panel mount design and thermal pad for heat dissipation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Harmony Solid State Relays, Solid state relay, 50A, panel mount, zero voltage switching, thermal pad, input 4…32V DC, output 48…530V AC
Brand: Clipsal
SKU: SSP3A250BDT
Alternatively Known As: Solid State Relay, SSR, Panel Mount Relay, Zero Voltage Switching Relay
Technical Specifications
- Rated current: 50A
- Input voltage: 4...32V DC
- Output voltage: 48...530V AC
- Insulation resistance: >= 1000 MOhm at 500 V DC
- IP Rating: IP20
- Response time: 8.33 ms
- Surge current: 715 A for 20 ms
- Maximum leakage current: 3 mA off-state
- Dielectric strength: 4 kV AC
- Dimensions (H x L x W): 74.6mm x 41mm x 104mm
- Weight: 0.37 kg
Key Features
- Zero voltage switching for efficient operation.
- Panel mount design with thermal pad for heat dissipation.
- LED indicator for input status.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, machinery control
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with IEC/EN 62314 and IEC/EN 60947 standards.
Environmental Benefits
- Energy-efficient design reduces power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Clipsal Harmony Solid State Relay 50A is available now for immediate purchase. Ideal for industrial automation and control applications.
