Solid State Relay | 90-280V AC Input | Zero-Crossing Switching | DIN Rail Mountable | @Pack of 1 | by Clipsal
The Solid State Relay is designed for high reliability in industrial automation, featuring a 90-280V AC input and zero-crossing switching to minimize electrical noise. Ideal for HVAC control panels and machinery, this compact DIN rail mountable relay includes an LED status indicator for easy diagnostics, ensuring efficient operation without mechanical wear.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Solid State Relay | 90-280V AC Input | Zero-Crossing Switching | DIN Rail Mountable | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHSSP1A110M7T
Alternatively Known As: Clipsal SSR, Solid State Switch, SCHSSP1A110M7T Relay, Electronic Relay, Industrial Solid State Relay
Technical Specifications
- Input Voltage: 90-280V AC
- Output Voltage: 24-280V AC
- Load Current: 1A
- Control Type: Zero-crossing
- Mounting: DIN rail
- Status Indicator: LED
- Isolation: Optical
- Operating Temperature: -30°C to +80°C
- Dimensions (H x L x W): 90mm x 100mm x 22.5mm
- Weight: 0.12 kg
Key Features
- Solid state switching for high reliability and long operational life
- Zero-crossing switching for reduced electrical noise
- Compact DIN rail mountable design
- LED status indicator for easy diagnostics
- No moving parts, ensuring silent operation
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with Australian electrical safety standards.
Applications
- Industrial automation systems
- HVAC control panels
- Lighting control
- Machinery and process control
- Building management systems
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- No mechanical wear, reducing waste and maintenance requirements
- Energy-efficient operation with minimal heat generation
- Long operational life reduces replacement frequency
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal SCHSSP1A110M7T Solid State Relay is available for immediate purchase. Ideal for industrial automation, HVAC, and process control applications.
