Solid State Slim Relay 0.1A | 16-30V DC Input | 1-48V DC Output | Compact 6mm by Clipsal
Solid state slim relay with 0.1A DC switching and 16-30V DC input—ideal for industrial control cabinets and automation systems. Built for silent operation, with compact 6mm design and IP67 rating for durability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Harmony Solid State Relays, Solid state slim relay, 0.1A, DC switching, input 16…30V DC, output 1…48V DC
Brand: Clipsal
SKU: SSL1D101BD
Alternatively Known As: Solid State Relay, Slim Relay, DC Relay, Plug-in Relay
Technical Specifications
- Rated current: 0.1A
- Control circuit voltage: 16...30V DC
- Output switching mode: DC switching
- Maximum operating frequency: 500 Hz
- Surge current: 0.3A for 10ms
- Response time: 0.02ms (turn-on), 0.13ms (turn-off)
- Dielectric strength: 3750V for input/output
- Dimensions (H x L x W): 28mm x 15mm x 6mm
- Weight: 0.0041 kg
Key Features
- Rated 0.1A with DC switching capability.
- Input voltage range of 16V to 30V DC.
- Output voltage range of 1V to 48V DC.
- Compact 6mm width design for space-saving.
- Silent operation with no moving contacts.
- IP67 rated for shock, vibration, and pollution resistance.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial: Control cabinets, automation systems, machinery
Standards & Compliance
- Complies with relevant safety and performance standards.
Environmental Benefits
- IP67 rating ensures durability in harsh conditions.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Clipsal Harmony Solid State Relay is available now for immediate purchase. Ideal for industrial applications requiring reliable DC switching.
