Solid State Slim Relay 0.1A 16-30VDC Input 1-48VDC Clipsal

BRAND: Clipsal
SKU: SCHSSL1D101BD
$25.80 List price: $32.20
+ −
30 Days Return Electricians Unlock Trade Access
Clipsal Solid State Slim Relay DC Input DC Output features 0.1A rated current, 16.30V DC and DC switching. 6mm width design.
Technical Specifications
  • Rated current: 0.1A
  • Control circuit voltage: 16...30V DC
  • Output switching mode: DC switching
  • Maximum operating frequency: 500 Hz
  • Surge current: 0.3A for 10ms
  • Response time: 0.02ms (turn-on), 0.13ms (turn-off)
  • Dielectric strength: 3750V for input/output
  • Dimensions (H x L x W): 28mm x 15mm x 6mm
  • Weight: 0.1 kg
Key Features
  • Rated 0.1A with DC switching capability.
  • Input voltage range of 16V to 30V DC.
  • Output voltage range of 1V to 48V DC.
  • Compact 6mm width design for space-saving.
  • Silent operation with no moving contacts.
  • IP67 rated for shock, vibration, and pollution resistance.
Professional Installation Requirements
  • Professional installation by a qualified technician is recommended for optimal performance.
Applications
  • Industrial: Control cabinets, automation systems, machinery
Standards & Compliance
  • Complies with relevant safety and performance standards.
Environmental Benefits
  • IP67 rating ensures durability in harsh conditions.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Clipsal Harmony Solid State Relay is available now for immediate purchase. Ideal for industrial applications requiring reliable DC switching.

SSL1D101BD (SSL1D101BD, 596 Kb) [Download]
