Sonata RT 3000 3000VA Pure Sinewave 2U Rack UPS Chase Power

BRAND: Chase Power
SKU: CP2316
$2,291.70 List price: $3,437.50
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Chase Power Sonata RT 3000 pure sinewave UPS 3000VA/2400W rack/tower 2U. Multi-OS power management for IT racks.

Alternatively Known As: Sonata RT 3000 UPS, 3000VA Rack UPS, 2U Pure Sinewave UPS, Line-Interactive UPS

Technical Specifications
  • UPS Topology: Line-interactive pure sinewave
  • Capacity: 3000VA / 2400W
  • Output Waveform: Pure sinewave
  • Form Factor: 2U rack or tower configurable
  • Input Requirement: 15A Australian power socket
  • Battery Configuration: 12V / 9Ah x 6
  • Battery Type: Hot-swappable, user-replaceable battery
  • Display: Rotatable LCD display
  • Communications: USB and smart RS-232; optional SNMP and AS400
  • Management Software: ViewPower smart management software
  • Operating System Support: Windows, Linux, Unix and Mac OS
  • Efficiency Features: ECO operation and programmable power management outlets
  • Net Weight: 35kg; manufacturer datasheet also lists 29.3kg for the standard model
  • Dimensions (H x L x W): 88mm x 640mm x 440mm
  • Weight: 35 kg
Key Features
  • 3000VA / 2400W capacity for IT and communications equipment
  • Pure sinewave output suitable for servers, networking and sensitive electronics
  • 2U rack-mount or tower installation configuration
  • Hot-swappable battery design for reduced maintenance interruption
  • Rotatable LCD display for rack or tower viewing
  • Programmable power outlets to prioritise critical loads and extend backup time
  • Emergency power off function
  • USB and RS-232 communications with optional SNMP monitoring
  • Supplied with rack-mount ears, tower stands, USB cable and Australian socket adaptor cable
Professional Installation Requirements
  • Installation and commissioning should be performed by a suitably qualified electrical or UPS technician. The unit requires a 15A supply and must be installed, earthed, ventilated and operated in accordance with the manufacturer's instructions and applicable Australian electrical requirements.
Applications
  • Server rooms and IT racks
  • Telecommunications and networking equipment
  • Surveillance and security systems
  • Business-critical computer systems
  • Equipment requiring SNMP or network-based UPS monitoring
Standards & Compliance
  • Applicable UPS safety standard: AS 62040.1, Uninterruptible power systems – General and safety requirements
  • Installation should comply with AS/NZS 3000 Wiring Rules where connected to Australian electrical installations
  • Product-specific Australian certification is not stated in the available manufacturer information
Environmental Benefits
  • ECO operating mode can reduce energy consumption and heat generation during suitable operating conditions
  • High-efficiency design helps reduce operating energy demand
  • Hot-swappable and user-replaceable batteries can extend service life and reduce whole-unit replacement waste
  • UPS batteries should be recycled through an approved battery recycling service at end of life
Warranty Information

Chase Power states that its UPS warranty is equal to or superior to comparable brands, but the specific warranty duration and battery coverage for the Sonata RT 3000 are not published in the available manufacturer information. Australian Consumer Law rights apply where applicable.

Available Now

Available through Chase Power and authorised Australian electrical, IT and power-quality distributors.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
