Special Control Station | IP66 Rated | Polycarbonate Enclosure | Surface Mount | @Pack of 1 | by Clipsal
The Special Control Station is designed for industrial automation, featuring a robust polycarbonate enclosure and IP66 rating for dust and water resistance. Ideal for machinery and equipment control, this surface-mounted station ensures reliable operation in commercial and manufacturing facilities, making it a perfect choice for process control applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Special Control Station | IP66 Rated | Polycarbonate Enclosure | Surface Mount | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHXAPM1501SPEC
Alternatively Known As: Clipsal control station, industrial control switch, Clipsal push button station, Clipsal SCHXAPM1501SPEC, Clipsal special switch
Technical Specifications
- Enclosure Material: Polycarbonate
- Ingress Protection: IP66
- Configuration: 1 x push button or switch
- Mounting: Surface mount
- Operating Temperature: -25°C to +60°C
- Colour: Grey with black actuator
- Rated Voltage: 250V AC
- Rated Current: 10A
- Dimensions (H x L x W): 68mm x 85mm x 68mm
- Weight: 0.4 kg
Key Features
- Robust and durable construction for industrial environments
- Single push button or switch configuration
- IP66 rated for dust and water resistance
- Clearly labelled for special control applications
- Easy installation with surface mounting
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local regulations and standards.
Applications
- Industrial automation control panels
- Machinery and equipment control
- Commercial and manufacturing facilities
- Process control stations
Standards & Compliance
- Complies with AS/NZS 60947 for low-voltage switchgear and controlgear
- Complies with AS/NZS 3820 for essential safety requirements for electrical equipment
Environmental Benefits
- Long-lasting design reduces replacement frequency and waste
- IP66 rating ensures protection against dust and water, supporting safe and sustainable operations
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Special Control Station SCHXAPM1501SPEC is available for immediate purchase. Ideal for industrial and commercial control applications requiring robust and reliable operation.
