Spring Lock Washer Shape A DIN 137 | Zinc Coated | Curved Design | @Pack of 50 | by Wurth
Spring Lock Washer Shape A DIN 137 is designed for reliable mechanical fastening, featuring a curved design and zinc coating for enhanced corrosion resistance. Ideal for automotive assembly and industrial machinery, this durable spring steel washer provides effective locking and vibration resistance, ensuring safety and longevity in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Spring Lock Washer Shape A DIN 137 | Zinc Coated | Curved Design | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 43410
Alternatively Known As: Spring lock washer, curved lock washer, DIN 137 washer, spring steel washer, zinc plated lock washer
Technical Specifications
- Suitable for screw thread: M10
- Internal diameter (d1): 10.5 mm
- Outer diameter (d2): 18 mm
- Height (h1): 4 mm
- Thickness (s1): 0.8 mm
- Material: Spring steel
- Surface: Zinc plated
- Design: Domed
- DIN Standard: 137
- Dimensions (H x L x W): 4mm x 18mm x 18mm
- Weight: 0.02 kg
Key Features
- Spring-loaded fastening element providing axial spring action
- Type A curved design for effective locking
- Mechanically applied zinc coating for corrosion resistance
- Made from durable spring steel
Professional Installation Requirements
- Installation by trained personnel recommended to ensure proper fastening and safety.
Applications
- Mechanical fastening applications requiring vibration resistance
- Automotive assembly and maintenance
- Industrial machinery and equipment fastening
- General purpose fastening in construction and manufacturing
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Zinc coating extends product life reducing waste
- Durable material reduces need for frequent replacements
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Spring Lock Washer Shape A DIN 137 is available for immediate purchase, ideal for mechanical and industrial fastening applications.
