Spring Lock Washer Shape B DIN 137 | Zinc Coated | Corrugated Design | Spring Steel | @Pack of 50 | by Wurth
Spring Lock Washer Shape B DIN 137 is designed for secure mechanical fastening, featuring a corrugated design and zinc coating for enhanced corrosion resistance. Ideal for automotive assembly and industrial machinery, this durable spring steel washer ensures reliable locking performance in various applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Spring Lock Washer Shape B DIN 137 | Zinc Coated | Corrugated Design | Spring Steel | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 4357
Alternatively Known As: Spring lock washer, DIN 137 washer, corrugated lock washer, zinc plated lock washer, spring steel washer
Technical Specifications
- Suitable for screw thread: M7
- Internal diameter (d1): 7.4 mm
- Outer diameter (d2): 14 mm
- Height (h1): 3 mm
- Thickness (s1): 0.8 mm
- Material: Spring steel
- Surface: Zinc plated
- Design: Corrugated
- Standard: DIN 137
- Dimensions (H x L x W): 3mm x 14mm x 14mm
- Weight: 0.01 kg
Key Features
- Spring-loaded locking element providing axial spring action
- Corrugated design for enhanced locking performance
- Mechanically applied zinc coating for corrosion resistance
- Made from durable spring steel
Professional Installation Requirements
- Installation by a qualified technician or engineer is recommended to ensure proper fastening and locking performance.
Applications
- Mechanical fastening applications requiring secure locking of screws and bolts
- Automotive assembly and maintenance
- Industrial machinery and equipment
- General engineering and construction
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Zinc coating provides corrosion resistance extending product life and reducing waste
- Durable spring steel construction reduces need for frequent replacements
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
Wurth Spring Lock Washer Shape B DIN 137 is available for immediate purchase, ideal for mechanical and industrial fastening applications.
