Spring Return Contact Block 1NO Base Mount | Reliable Momentary Switching | High Mechanical Durability | by Clipsal
The Spring Return Contact Block 1NO Base Mount is designed for reliable momentary switching in industrial control panels and automation systems. Featuring a spring return mechanism and a 1NO contact configuration, this block ensures high mechanical durability, making it ideal for machinery start/stop stations and process control equipment. With screw clamp terminals for secure wiring, it's built for long-lasting performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Spring Return Contact Block 1NO Base Mount | Reliable Momentary Switching | High Mechanical Durability | by Clipsal
Brand: Clipsal
SKU: SCHXACS101
Alternatively Known As: momentary contact block, spring return contact, 1NO contact block, base mount contact block, SCHXACS101
Technical Specifications
- Contact Configuration: 1 Normally Open (1NO)
- Mounting Type: Base mounting
- Spring return mechanism for momentary operation
- Rated Operational Voltage: 600V AC max
- Rated Operational Current: 10A
- Terminal Type: Screw clamp
- Mechanical Durability: Over 1,000,000 operations
- Insulation Voltage: 690V
- Conforms to IEC 60947-5-1
- Dimensions (H x L x W): 40mm x 40mm x 30mm
- Weight: 0.1 kg
Key Features
- Spring return mechanism for reliable momentary switching
- 1NO (Normally Open) contact configuration
- Base mounting for easy installation
- High mechanical durability for industrial environments
- Screw clamp terminals for secure wiring
Professional Installation Requirements
- Installation by a qualified electrician or technician is required to ensure compliance with safety standards.
Applications
- Industrial control panels
- Automation systems
- Machinery start/stop stations
- Process control equipment
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable design reduces replacement frequency and electronic waste
- Reliable operation minimizes downtime and maintenance
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Spring Return Contact Block 1NO Base Mount (SCHXACS101) is available for immediate purchase. Ideal for industrial automation and control panel applications.
