Stainless Steel Countersunk Rivet M10 | Corrosion Resistant | Small Countersunk Head | High Tensile Strength | by Wurth
The Stainless Steel Countersunk Rivet M10 is designed for industrial fastening applications, featuring a corrosion-resistant A2 stainless steel construction and a small countersunk head for a flush finish. With a high tensile fracture load of 47040 N and a shear-fracture load of 5010 N, this rivet is perfect for mechanical assembly and construction projects, ensuring secure fastening in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Material: Stainless steel A2
- Surface: Plain
- Thread type x nominal diameter (D): M10
- Width across flats: 13 mm
- Length (l1): 20.5 mm
- Head diameter (d1): 14.5 mm
- Head height (k1): 1.1 mm
- Min./max. grip range (s1): 0.8-4 mm
- Tensile fracture load: 47040 N
- Shear-fracture load: 5010 N
- Max. tightening torque: 40 Nm
- Shank detail: With partial hexagon shank
- Head type: Small countersunk head
- Dimensions (H x L x W): 1.1mm x 20.5mm x 14.5mm
- Weight: 0.1 kg
Key Features
- Made from stainless steel A2 for corrosion resistance
- Small countersunk head design for flush finish
- Partial hexagon shank for secure fastening
- RoHS-compliant ensuring environmental safety
- High tensile fracture load of 47040 N
- Shear-fracture load of 5010 N
- Max tightening torque of 40 Nm
Professional Installation Requirements
- Installation should be performed by trained personnel using appropriate tools to ensure correct torque and secure fastening.
Applications
- Industrial fastening applications
- Mechanical assembly requiring strong, corrosion-resistant rivets
- Construction and manufacturing projects
Standards & Compliance
- AS/NZS 4762 – High strength structural bolts (relevant for fasteners)
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Stainless steel construction enhances product longevity, reducing waste
Warranty Information
Standard manufacturer warranty applies; please refer to Wurth's warranty policy for details.
Available Now
Available for immediate purchase, ideal for industrial, construction, and mechanical fastening applications.
