Trade Discount 20%
Stainless Steel Drill Bit M6 | High Alloy Steel | Extra-Long Groove | Premium Quality | by Wurth
The Stainless Steel Drill Bit M6 is designed for precision machining of alloyed and high-alloyed steels, including stainless and rust-resistant materials. With a newly developed geometry for efficient chip removal and a homogenised surface structure, this drill bit offers up to 50% longer service life compared to conventional taps. Ideal for professional use with milling and drilling machines, it ensures optimal performance and safety in demanding applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Stainless Steel Drill Bit M6 | High Alloy Steel | Extra-Long Groove | Premium Quality | by Wurth
Brand: Wurth
SKU: 655700600
Alternatively Known As: Stainless Steel Drill Bit, High Alloy Steel Drill Bit, M6 Thread Cutter, HSCo Drill Bit
Technical Specifications
- Thread type: Metric thread M6 x 1.0 mm pitch
- Material to be processed: Stainless steel, Steel
- Hole type: Clearance hole approx. 3xD
- Suitable for machine type: Milling/drill center, Pedestal drilling machine
- Quality: ZEBRA-Premium
- Length: 80 mm
- Shank diameter: 6.0 mm
- Size of square: 4.9 mm
- DIN standard: 371
- Cutting material: HSCo
- Surface: Plain
- Form: D
- Core hole diameter: 5.0 mm
- Shank style: Cylindrical with square drive
- Tolerance of screw taps: ISO 2X (6HX)
- Suitable for tensile strength up to: 1200 N/mm²
- Service life rating: 3 of 4 points
- Trueness to gauge rating: 4 of 4 points
- Versatility rating: 3 of 4 points
- Cutting behaviour rating: 3 of 4 points
- Chip formation rating: 3 of 4 points
- Material sub-groups: Stainless steels (sulphurated, austenitic, martensitic), general structural steels, non-alloyed and alloyed tempering steels, nitriding steels, tool steels, high-speed steels
- Dimensions (H x L x W): 6mm x 80mm x 6mm
- Weight: 0.1 kg
Key Features
- Newly developed geometry combining a left-hand spiral and a spiral point tap
- Homogenised surface structure due to state-of-the-art finishing process
- Extra-long groove for efficient chip removal
- Cutting edge geometry precisely tailored to stainless steel
- Up to 50% longer service life compared to conventional plain machine taps
- Exclusive availability from Wurth
- Product packaging made from 100% PCR recycled plastic and is 100% recyclable
Professional Installation Requirements
- Professional use recommended with appropriate machine tools and safety equipment for optimal performance and safety.
Applications
- Processing alloyed and high-alloyed steels including stainless, rust-resistant, and acid-resistant steels
- Suitable for conventional steel materials up to 1200 N/mm² strength
- Use with milling/drill centers and pedestal drilling machines
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Packaging made from 100% post-consumer recycled plastic and is fully recyclable, reducing environmental impact
Warranty Information
Standard manufacturer warranty applies. Please refer to Wurth for detailed warranty terms.
Available Now
The Wurth Specialist Drill Bit M6 x 80mm is available for immediate purchase, ideal for machining applications involving stainless and alloyed steels.
