Stainless Steel Hex Socket Screw M3x20 | Corrosion Resistant | ISO 7380-1 Compliant | @Pack of 50 | by Wurth
Stainless Steel Hex Socket Screw M3x20 is designed for reliable mechanical fastening in corrosion-prone environments. With excellent corrosion resistance and compliance with ISO 7380-1 standards, this screw is perfect for applications exposed to moisture or chemicals. Ideal for light to moderate load fastening, it features a button head with a hexagon socket drive for secure fastening.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Stainless Steel Hex Socket Screw M3x20 | Corrosion Resistant | ISO 7380-1 Compliant | @Pack of 50 | by Wurth
Brand: Wurth
SKU: 9901320
Alternatively Known As: Button head hex socket screw, ISO 7380-1 screw, Stainless steel hex socket screw M3x20
Technical Specifications
- Thread type x nominal diameter: M3
- Length: 20 mm
- Head diameter: 5.7 mm
- Head height: 1.65 mm
- Standards: ISO 7380-1
- Material: Stainless steel A4
- Property class: 070
- Surface finish: Plain
- Head type: Button head
- Drive type: Hexagon socket (HS2)
- Thread form: Standard metric thread
- Product class: A
- RoHS-compliant: Yes
- Dimensions (H x L x W): 1.65mm x 20mm x 5.7mm
- Weight: 0.002 kg
Key Features
- Stainless steel A4 material offers excellent corrosion resistance
- Button head with hexagon socket drive for secure fastening
- Complies with ISO 7380-1 standard
- RoHS-compliant
- Limited load capacity due to head geometry as per DIN EN ISO 3506-1
Professional Installation Requirements
- Installation by a qualified technician or engineer is recommended to ensure correct torque and load application.
Applications
- General mechanical fastening applications requiring corrosion resistance
- Use in environments exposed to moisture or chemicals
- Suitable for light to moderate load fastening where button head screws are preferred
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Stainless steel material ensures long product life reducing replacement frequency
- RoHS-compliant, free from hazardous substances
Warranty Information
Warranty against manufacturing defects as per Wurth standard terms and conditions.
Available Now
Available for immediate purchase, ideal for mechanical fastening in corrosion-prone environments.
