Street Lighting Fuse 32A | 415V AC | 80 kA Breaking Capacity | gG/gL Class by Eaton
Street lighting fuse with a 32A amperage rating and 415V AC voltage—ideal for low voltage electrical circuits. Built for industrial and commercial installations, with a high breaking capacity of 80 kA for reliable protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Street Lighting Fuse 32A | 415V AC | 80 kA Breaking Capacity | gG/gL Class by Eaton
Brand: Eaton
SKU: SMD32
Alternatively Known As: Low Voltage Fuse 32A, British Standard Fuse 32 Amp, 415V Fuse, SMD32 Fuse
Technical Specifications
- Amperage Rating: 32 A
- Voltage Rating: 415 V AC
- Breaking Capacity: 80 kA
- Fuse Type: SMD
- Class: gG/gL
- Construction: BS88
- Dimensions: 13 x 29 mm
- Certifications: BS88 IEC 60269 EAC
- Compliances: CE Marked, RoHS Compliant
- Dimensions (H x L x W): 16mm x 29mm x 16mm
- Weight: 0.012 kg
Key Features
- 32A amperage rating
- 415V AC voltage rating
- Breaking capacity of 80 kA
- Class gG/gL fuse type for general purpose protection
- Complies with BS88 and IEC 60269 standards
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with safety standards and proper fuse selection.
Applications
- Street lighting protection
- Low voltage electrical circuits
- Industrial and commercial electrical installations
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS compliant, ensuring reduced hazardous substances
- CE marked for safety and environmental standards
Warranty Information
Warranty as per Eaton standard terms and conditions.
Available Now
The Eaton Bussmann Series Low Voltage British Standard Fuse 32A 415V is available for immediate purchase, ideal for street lighting and low voltage electrical protection.
