Trade Discount 21%
Stud with Threaded End M8x20 DIN 939 Steel 5.8 | Zinc Plated Blue Passivated | @Pack of 10 | by Wurth
The Stud with Threaded End M8x20 DIN 939 Steel 5.8 is designed for robust mechanical fastening in various applications, including automotive and construction. With a corrosion-resistant zinc plating and a property class of 5.8, this headless stud ensures reliable performance and compliance with DIN standards. Ideal for professionals seeking durable and safe fastening solutions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Stud with Threaded End M8x20 DIN 939 Steel 5.8 | Zinc Plated Blue Passivated | @Pack of 10 | by Wurth
Brand: Wurth
SKU: 250608020
Alternatively Known As: Threaded Stud M8, DIN 939 Stud, Zinc Plated Threaded Rod, Steel Threaded Stud
Technical Specifications
- Thread type x nominal diameter (d1): M8
- Length (l1): 20 mm
- Thread length (metric thread) (l2): 13.8 mm
- Thread length 2 (metric thread) (l3): 10 mm
- Standards: DIN 939
- Material: Steel
- Property class: 5.8
- Surface: Zinc plated with blue passivation
- RoHS-compliant: Yes
- Head type: Without head
- Drive type: Without drive
- Thread type: Metric thread
- Pitch: 1.25 mm
- Thread form: Standard metric thread
- Shank diameter: 8 mm
- Product class: A
- Dimensions (H x L x W): 20mm x 20mm x 8mm
- Weight: 0.02 kg
Key Features
- Thread type: Metric thread M8 with 1.25 mm pitch
- Length: 20 mm with 13.8 mm and 10 mm thread lengths
- Material: Steel with property class 5.8 for strength
- Surface finish: Zinc plated with blue passivation for corrosion resistance
- Complies with DIN 939 standard
- RoHS-compliant ensuring environmental safety
- Headless design without drive for specific fastening needs
Professional Installation Requirements
- Installation by a qualified technician or tradesperson is recommended to ensure proper fastening and safety.
Applications
- Mechanical fastening in machinery and equipment
- Automotive assembly and repair
- Construction and structural applications requiring threaded studs
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- RoHS-compliant material reduces hazardous substances
- Zinc plating extends product life reducing waste and replacement frequency
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
The Wurth Stud with Threaded End M8x20 DIN 939 Steel 5.8 Zinc Plated Blue Passivated is available for immediate purchase, ideal for mechanical, automotive, and construction fastening applications.
