Sunset Switch Weatherproof 16A 240V IP66 S-Click
S-Click weatherproof sunset switch features 16A 240V rating, IP66, 25 lux on and 50 lux off with 4 programmable modes. Ideal for dusk to dawn outdoor lighting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: S-Click Weatherproof Sunset Switch, Photoelectric Daylight Switch, Outdoor Light Sensor Switch, Dusk-to-Dawn Switch
Technical Specifications
- Model: HSC110SS
- Operating Voltage: 220–240V AC
- Frequency: 50Hz
- Maximum Current: 16A
- Maximum Load: 3840W incandescent and halogen; 3840VA fluorescent
- Light Levels: ON at 25 lux; OFF at 50 lux
- Operating Temperature: 0°C to +50°C
- Ingress Protection: IP66 when all used and unused cable entries are sealed
- Operating Modes: Standard dusk-to-dawn, delay timer, ECO and real time
- Programming: Eight internal DIP switches
- Turn-On/Off Delay: 1 minute
- Timer Steps: 30 minutes
- Delay Timer Range: 30 minutes to 15.5 hours
- Warm-Up Time: Approximately 30 seconds
- Terminals: Heavy-duty brass screw terminals
- Material: Polycarbonate enclosure
- Load Compatibility: Incandescent, halogen and fluorescent lighting
- Installation Type: Fixed-wire electrical installation
- Dimensions (H x L x W): 76mm x 118mm x 92mm
- Weight: 0.276 kg
Key Features
- Automatically switches outdoor lighting according to ambient light levels
- Four programmable operating modes for flexible lighting control
- ECO mode reduces unnecessary overnight lighting and adapts to seasonal changes
- Real Time mode switches lights off at a consistent programmed time each night
- Weatherproof IP66 enclosure for suitable outdoor installations
- Factory calibrated photoelectric sensor with short warm-up time
- Can be retrofitted to compatible HPM bases
- Supplied with cable glands, DIP switch tool and installation instructions
- Large brass terminals support secure electrical connections
Professional Installation Requirements
- Installation must be performed by a licensed electrician or suitably qualified electrical contractor as part of a fixed-wire electrical installation. All cable entries must be correctly sealed to maintain the IP66 rating, and installation must follow the manufacturer's instructions and AS/NZS 3000 wiring requirements.
Applications
- Outdoor security lighting
- Walkways and paths
- Verandas and courtyards
- Car parks and commercial outdoor areas
- Residential exterior lighting
- Commercial and industrial dusk-to-dawn lighting control
Standards & Compliance
- AS/NZS 61347.2.11
- CISPR 15
- IP66 ingress protection classification in accordance with AS/NZS 60529
Environmental Benefits
- Reduces electricity consumption by switching lighting on only when ambient light is low
- ECO, timer and real-time modes can reduce unnecessary overnight lighting operation
- Durable weatherproof construction can extend service life and reduce replacement waste
- Supports more efficient control of outdoor lighting systems
Warranty Information
CABAC's general warranty provides repair or replacement for defects for 12 months from the date of purchase or supply, subject to correct installation, operation within specification and exclusion of misuse, neglect and incorrect installation. Australian Consumer Law rights apply separately.
Available Now
Available through S-Click/CABAC and authorised Australian electrical distributors.
