'Surface Mount Downlight 125x52mm 10/12W White Haneco'
'Haneco surface mount downlight features 125x52mm size, 10/12W power and 3000/4000/5000K CCT with IP54 diffuser in white. Ideal for ceilings without recess depth.'
Sign in
Please login to continue to your account.
Alternatively Known As: Haneco M12W125R-EV, Meteor EVO 10/12W Surface Mount Downlight, Tri-Colour Surface-Mounted LED Downlight
- Product Code: M12W125R-EV
- Power: Selectable 10W or 12W
- Input Voltage: 220–240 V AC, 50/60 Hz
- Lumen Output: 10W: 926/1000/951 lm; 12W: 1077/1200/1131 lm
- Colour Temperature: Selectable 3000K, 4000K or 5000K
- Efficacy: 10W: 103/117/108 lm/W; 12W: 98/115/104 lm/W
- Beam Angle: 110°
- Colour Rendering: CRI greater than 80
- Dimming: Phase-cut dimmable, trailing edge, 10–100%
- Ingress Protection: IP54 front and body
- Material: Polycarbonate body and diffuser
- Electrical Classification: Class II
- Driver: Integral, flicker-free
- Power Factor: Greater than 0.9
- Operating Temperature: -20°C to 40°C
- Projected Lifespan: 102,000 hours at 25°C, L80
- Finish: White, RAL 9016
- Smart Compatibility: KASTA compatible
- Dimensions (H x L x W): 52mm x 125mm x 125mm
- Weight: 0.3 kg
- Surface-mounted design for ceilings without sufficient recess depth
- Slim 52 mm profile suitable for shallow ceiling spaces and exposed concrete slabs
- Selectable 10W or 12W output
- Selectable 3000K, 4000K and 5000K colour temperature
- Opal diffuser for soft, uniform illumination
- IP54 protection for indoor and sheltered outdoor applications
- Phase-cut dimmable with trailing-edge dimmers
- Flicker-free integral driver
- KASTA compatible
- White polycarbonate construction
- Installation must be performed by a licensed electrician in accordance with the manufacturer’s instructions, applicable Australian standards and local regulations. The fitting uses a 220–240 V AC supply and has a non-user-replaceable light source.
- Residential and commercial ceiling lighting
- Apartments and high-rise buildings
- Bathrooms, laundries and other suitable wet rooms
- Corridors, entrances and hallways
- Balconies, patios, verandahs and awnings
- Garages and walk-in wardrobes
- Kitchens, food preparation areas and function spaces
- Hotels, restaurants, cafés and common areas
- Applicable luminaire safety requirements: AS/NZS 60598.1 for general requirements and tests; verify the product-specific Haneco Supplier Declaration of Conformity before installation. ([inus04aapb1h3nprod.dxcloud.episerver.net](https://inus04aapb1h3nprod.dxcloud.episerver.net/en-au/standards/as-nzs-60598-1-2017-99555_saig_as_as_209293/))
- LED technology provides lower energy consumption than conventional halogen or incandescent lighting for comparable illumination
- Long projected service life of 102,000 hours at L80 can reduce replacement frequency and associated waste
- Selectable wattage allows output and energy use to be matched to the application
- Polycarbonate construction is durable and may support extended product life
- Flicker-free, high-efficacy operation supports efficient lighting-system design
Haneco provides a direct-replacement warranty against manufacturing defects of 3–5 years unless otherwise stated. The METEOR EVO product listing identifies a 5-year warranty; claims require proof of purchase and installation by an authorised electrician. Removal and reinstallation labour is generally excluded. ([haneco.com.au](https://haneco.com.au/wp-content/uploads/2026/01/Product-Warranty-2026.pdf))
Available through Haneco and authorised Australian electrical wholesalers and distributors.
