Surface Mount Reed Switch Aluminium Housing NC/NO 100V DC Tecom

BRAND: Ness
SKU: 122-148
$64.30 List price: $85.70
+ −
30 Days Return Electricians Unlock Trade Access
Tecom surface mount reed switch features an aluminium housing, NC/NO configuration and 100V DC rating. Ideal for door contacts in alarm systems.

Alternatively Known As: Aluminium Surface-Mount Magnetic Contact, Wide-Gap Door Contact, Armoured Cable Reed Switch, Aritech 2505A-L

Technical Specifications
  • Housing Material: Brushed anodised aluminium
  • Contact Configuration: NC/NO loop configuration, subject to model wiring
  • Switching Voltage: 100 V AC/DC maximum
  • Switching Current: 0.5 A maximum
  • Switching Power: 7.5 W maximum
  • Nominal Sense Gap: 76 mm
  • Cable: 914 mm stainless-steel armoured cable
  • Magnet: Matching actuator magnet included
  • Mounting: Surface mount with approximately 50.8 mm hole centres
  • Contact Type: Hermetically sealed reed switch
  • Listings: UL/ULC and UL 634 listed for the 2500 Series
  • Dimensions (H x L x W): 25.4mm x 76.2mm x 12.7mm
  • Weight: 0.38 kg
Key Features
  • Rugged aluminium housing for commercial and industrial installations
  • Wide operating gap helps accommodate movement in doors, gates and overhead openings
  • Stainless-steel armoured cable protects the lead in exposed installations
  • Hermetically sealed reed switch helps resist moisture and contact contamination
  • Suitable for hardwired security alarm and access-control systems
  • Passive switching device with no standby power consumption
Professional Installation Requirements
  • Installation should be performed by a qualified security technician or electrician. Align the contact and magnet correctly and connect the loop wiring in accordance with the alarm system design and manufacturer instructions.
Applications
  • Security alarm door and window monitoring
  • Metal doors, overhead doors, fences and gates
  • Commercial and industrial access-control systems
  • Garage doors, freezers and other large moving openings
  • Perimeter protection requiring a wide magnetic operating gap
Environmental Benefits
  • Aluminium housing is recyclable at end of service life
  • Passive reed-switch operation does not require standby power
  • Long service life and robust construction can reduce replacement frequency and waste
  • Sealed construction helps protect the component from moisture-related premature failure
Warranty Information

Tecom and Carrier intrusion-system warranty documentation lists hardwired contacts, hardwired sensors, passive modules and components with a five-year warranty, subject to testing, verification and applicable supplier terms.

Available Now

Available through Tecom, Aritech and authorised Australian security-equipment distributors, subject to current range and distributor stock.
