Surface Switch IP66 1G 4P 20A Resistant Orange Clipsal
Clipsal Surface Switch Resistant Orange features 500V AC 50Hz, 20A rated current and Polycarbonate. IP66 rated for protection against dust and water.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Rated operational voltage: 500 V AC 50 Hz
- Rated current: 20 A
- Material: Polycarbonate
- Breaking capacity: 20 kA
- Rated short-circuit making capacity: 1.7 kA
- Rated impulse withstand voltage: 4 kV
- Rated short-time withstand current: 0.8 kA for 1 s
- Tightening torque: 0.8 N.m
- Dimensions (H x L x W): 107mm x 72mm x 101mm
- Weight: 0.28 kg
Key Features
- IP66 rated for protection against dust and water
- 4-pole switch function
- Rotary knob control type
- Suitable for isolation
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Small commercial utility industry
Standards & Compliance
- Complies with AS/NZS 3133 and AS 60529 for safety and performance standards.
Environmental Benefits
- Compliant with RoHS directives and environmental regulations.
Warranty Information
Standard warranty applies.
Available Now
The Clipsal 56 Series Surface Switch IP66 1 Gang 4 Pole 20A is available now for immediate purchase. Ideal for small commercial and industrial applications.
