Surge Protection Device 150V | DIN Rail Mount | IP20 Rated by NHP
Surge protection device with 150V nominal voltage and DIN rail mounting—ideal for residential and commercial surge protection. Built for safety, with IP20 rating and easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cirprotec Final Diverters SPD Comm Fine Protect 150V
Brand: NHP
SKU: CPTDIN150V2C
Alternatively Known As: Surge Protection Device, Final Diverter, SPD 150V
Technical Specifications
- Nominal Voltage AC: 150 V
- Max Continuous Voltage AC: 180 V
- Nominal Discharge Surge Current (8/20): 5 kA
- Max Discharge Surge Current (8/20): 10 kA
- Lightning Impulse Current (10/350 µs): 10 kA
- Voltage Protection Level (Core-Earth): 200 V
- Frequency: 5000000 MHz
- Number of Protected Wires: Other
- Mounting Method: DIN rail (top hat rail) 35 mm
- Degree of Protection: IP20
- Max Conductor Cross Section: 2.5 mm²
- Dimensions (H x L x W): 90mm x 70mm x 17.5mm
- Weight: 0.06 kg
Key Features
- Surge Protection Device designed for final protection against surges.
- DIN rail mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, offices
- Commercial: Retail, hospitality, workspaces
- General: Any location requiring surge protection for electrical systems
Standards & Compliance
- Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
- Protects electrical systems, reducing the risk of damage and waste from surge-related failures.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Cirprotec Final Diverters SPD Comm Fine Protect 150V is available now for immediate purchase. Ideal for residential and commercial applications requiring surge protection.
Non-Returnable & Non-Cancellable
