Surge Protection Device 1P T2 | 320V Uc | 40kA In | Remote Contact by Hager

BRAND: :hager
SKU: SPB100R
$226.00 List price: $288.90
+ −
30 Days Return Delivery Options
Surge protection device with 320V continuous operating voltage and 40kA nominal discharge current—ideal for residential, commercial, and industrial applications. Built for enhanced monitoring with remote contact and compliance with AS/NZS 60950 standards.

Product Name/Title: Surge Protection Device 1P T2 TNC Uc 320V In 40kA Imax 100kA remote contact

Brand: Hager

SKU: SPB100R

Alternatively Known As: Surge Protector, Surge Suppressor, Voltage Surge Protection Device

Technical Specifications
  • Capacity: 1 module
  • Voltage protection level Up: 2 kV
  • Voltage protection level Up L-PE/N-PE: 1.70 kV
  • Max. overcurrent protection device: 250 A
  • Operating temperature: -40 to 80 °C
  • Network configuration: TN-C, TT
  • Frequency: 50 - 60 Hz
  • Nominal tightening torque: 3 - 3 Nm
  • Dimensions (H x L x W): 97mm x 78mm x 18mm
  • Weight: 0.5 kg
Key Features
  • Rated operational voltage of 240 - 415 V.
  • Continuous operating voltage Uc of 320 V.
  • Nominal discharge current In of 40 kA.
  • Max discharge (Imax) of 100 kA.
  • Remote signalling contact for enhanced monitoring.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes and apartments
  • Commercial: Offices and retail spaces
  • Industrial: Factories and manufacturing facilities
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • RoHS compliant, reducing hazardous substances in electrical equipment.
  • Halogen-free materials contribute to safer disposal and recycling.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager Surge Protection Device 1P T2 TNC Uc 320V is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.

SPB100R (SPB100R, 96 Kb) [Download]

PEP_HAGER_HAGE_00444_V01.01_EN_27082021.pdf (PEP_HAGER_HAGE_00444_V01.01_EN_27082021.pdf, 231 Kb) [Download]

reach_declaration_SPB100R.pdf (reach_declaration_SPB100R.pdf, 103 Kb) [Download]

rohs_declaration_SPB100R.pdf (rohs_declaration_SPB100R.pdf, 104 Kb) [Download]

ID1_SPBXXXR_6LE007645AA.pdf (ID1_SPBXXXR_6LE007645AA.pdf, 828 Kb) [Download]

(SURGE_BROCHURE_AUS_LOWRES.pdf, 934 Kb) [Download]

(DECLARATION_21_2979_07_21.pdf, 306 Kb) [Download]
