Surge Protection Device 24V | 4 Wires | DIN Rail Mount | IP20 by NHP
Surge protection device with 24V nominal voltage and 4 protected wires—ideal for industrial and commercial applications. Built for final stage protection, with easy DIN rail mounting and IP20 rating.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cirprotec Final Diverters SPD Analogue 24V 4 Wires
Brand: NHP
SKU: CPTDIN24V5N
Alternatively Known As: Surge Protection Device, Final Diverter, SPD 24V
Technical Specifications
- Nominal Voltage AC: 24 V
- Max Continuous Voltage AC: 16 V
- Nominal Discharge Surge Current (8/20): 5 kA
- Max Discharge Surge Current (8/20): 10 kA
- Lightning Impulse Current (10/350 µs): 10 kA
- Voltage Protection Level (Core-Earth): 67 V
- Frequency: 500000 MHz
- Number of Protected Wires: 4+GND
- Mounting Method: DIN rail (top hat rail) 35 mm
- Degree of Protection: IP20
- Max Conductor Cross Section: 2.5 mm²
- Dimensions (H x L x W): 90mm x 60mm x 36mm
- Weight: 0.08 kg
Key Features
- Surge Protection Device designed for final stage protection.
- 4 protected wires plus ground for comprehensive coverage.
- DIN rail mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Protecting sensitive equipment from voltage surges
- Commercial: Ensuring the safety of electrical installations
Standards & Compliance
- Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
- Protects electrical systems, reducing waste from damaged equipment.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Cirprotec Final Diverters SPD Analogue 24V 4 Wires is available now for immediate purchase. Ideal for industrial and commercial applications requiring surge protection.
