Surge Protection Device 24V | 7 Wires | DIN Rail Mount | IP20 by NHP
Surge protection device with 24V nominal voltage and 7 wires—ideal for industrial and commercial data networks. Built for final stage protection, with easy DIN rail mounting and IP20 indoor rating.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cirprotec Final Diverters SPD Analogue 24V 7 Wires
Brand: NHP
SKU: CPTDIN24V8
Alternatively Known As: Surge Protection Device, Final Diverter, SPD for Data Networks
Technical Specifications
- Nominal Voltage AC: 24 V
- Max Continuous Voltage AC: 16 V
- Nominal Discharge Surge Current (8/20): 5 kA
- Max Discharge Surge Current (8/20): 10 kA
- Lightning Impulse Current (10/350 µs): 10 kA
- Voltage Protection Level (Core-Core): 67 V
- Voltage Protection Level (Core-Earth): 67 V
- Voltage Protection Level (Core-Signal Ground): 39 V
- Frequency: 3000000 MHz
- Number of Protected Wires: Other
- Mounting Method: DIN rail (top hat rail) 35 mm
- Degree of Protection: IP20
- Max Conductor Cross Section: 2.5 mm²
- Dimensions (H x L x W): 90mm x 60mm x 52.5mm
- Weight: 0.11 kg
Key Features
- Surge Protection Device designed for final stage protection.
- IP20 rated for indoor use.
- DIN rail mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Protection of electrical installations and equipment from surges.
- Commercial: Suitable for data networks and MCR technology.
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Protects sensitive equipment from voltage spikes, reducing waste and prolonging equipment life.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Cirprotec Final Diverters SPD Analogue 24V 7 Wires is available now for immediate purchase. Ideal for industrial and commercial applications requiring surge protection.
Non-Returnable & Non-Cancellable
