Surge Protection Device IPRD 40R | 40kA Maximum Discharge | 350V Rated Voltage | DIN Rail Mount | @Pack of 1 | by Clipsal
The IPRD 40R Surge Protection Device is designed to safeguard your electrical systems with a maximum discharge current of 40kA and a rated voltage of 350V. Ideal for residential, commercial, and industrial applications, this Type 2 SPD features a visual status indicator and a plug-in module for easy replacement, ensuring reliable protection against transient overvoltages.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Surge Protection Device IPRD 40R | 40kA Maximum Discharge | 350V Rated Voltage | DIN Rail Mount | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHA9L40301
Alternatively Known As: Surge Protection Device, SPD 40kA, Clipsal Surge Protector, SCHA9L40301, Type 2 SPD, 350V Surge Arrestor
Technical Specifications
- Type: Type 2 surge protection device
- Rated voltage: 350V AC
- Nominal discharge current (In): 20kA
- Maximum discharge current (Imax): 40kA
- Voltage protection level (Up): ≤1.5kV
- Mounting: DIN rail
- Status indicator: Visual
- Replaceable module
- Dimensions (H x L x W): 90mm x 70mm x 36mm
- Weight: 0.25 kg
Key Features
- Type 2 surge protection device
- Nominal discharge current (In): 20kA
- Maximum discharge current (Imax): 40kA
- Voltage protection level (Up): ≤1.5kV
- Rated voltage: 350V AC
- Plug-in module for easy replacement
- Visual indicator for device status
- Compact DIN rail mounting
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules and local regulations.
Applications
- Residential and commercial electrical distribution boards
- Industrial switchboards
- Protection of sensitive electronic equipment from transient overvoltages
- Suitable for use in main and sub-distribution boards
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 1768 – Lightning Protection
Environmental Benefits
- Protects electrical and electronic equipment, reducing electronic waste from damage
- Enhances system reliability, minimizing downtime and maintenance
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal IPRD 40R 40kA 350V Surge Protection Device (SCHA9L40301) is available for immediate purchase. Ideal for protecting electrical installations in residential, commercial, and industrial environments.
