Surge Protection Device N-PE | 40kA Nominal | 100kA Max | 260V by Hager
Surge protection device with 40kA nominal and 100kA max discharge current—ideal for residential and commercial surge protection. Built for safety and performance, with RoHS and REACH compliance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cartridge N-PE Uc 260V In 20kA Imax 100kA Up 1,5kV
Brand: Hager
SKU: SPB010N
Alternatively Known As: Surge Protection Device, SPD, Modular Circuit Protection Device
Technical Specifications
- Capacity Number of modules: 1
- Rated operational voltage Ue: 240 - 415 V
- Continuous operating voltage Uc: 264 V
- Voltage protection level Up: 1.7 kV
- Nominal discharge current In: 40 kA
- Max discharge (Imax): 100 kA
- Network type: TN-S, TT
- Connection cross-section for flexible conductors: 1.5 - 25.0 mm²
- Connection cross-section for massive conductors: 1.5 - 35.0 mm²
- Frequency: 50 - 60 Hz
- Nominal tightening torque: 3 - 3 Nm
- Dimensions (H x L x W): 47mm x 67mm x 18mm
- Weight: 0.5 kg
Key Features
- Nominal discharge current of 40 kA.
- Maximum discharge current of 100 kA.
- Operating temperature range from -40 to 80 °C.
- RoHS and REACH compliant.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, offices
- Commercial: Retail, hospitality, workspaces
- General: Any installation requiring surge protection
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Commitment to reducing carbon footprint and improving environmental performance.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager Cartridge N-PE Uc 260V Surge Protection Device is available now for immediate purchase. Ideal for residential and commercial spaces requiring surge protection.
