Surge Protection Device RS485 | 5kA Discharge | DIN Rail Mount | IP20 by NHP
Surge protection device with RS485 compatibility and 5kA nominal discharge—ideal for data networks and telecommunications. Built for easy installation with DIN rail mounting and IP20 indoor protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cirprotec Final Diverters SPD RS485 1 Pair
Brand: NHP
SKU: CPTDIN4852C
Alternatively Known As: Surge Protection Device, SPD for RS485, Final Diverter
Technical Specifications
- Nominal Voltage AC: 48 V
- Max Continuous Voltage AC: 180 V
- Nominal Discharge Surge Current (8/20): 5 kA
- Max Discharge Surge Current (8/20): 10 kA
- Lightning Impulse Current (10/350 µs): 10 kA
- Voltage Protection Level Core-Earth: 20 V
- Frequency: 5000000 MHz
- Number of Protected Wires: Other
- Mounting Method: DIN rail (top hat rail) 35 mm
- Degree of Protection: IP20
- Max Conductor Cross Section: 2.5 mm²
- Dimensions (H x L x W): 90mm x 70mm x 17.5mm
- Weight: 0.06 kg
Key Features
- Designed for surge protection in data networks.
- DIN rail mounting for easy installation.
- IP20 rated for indoor use.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and safety.
Applications
- Surge protection for data networks
- Industrial applications
- Telecommunications
Standards & Compliance
- Complies with relevant Australian standards for surge protection devices.
Environmental Benefits
- Helps protect sensitive electronic equipment from voltage spikes.
Warranty Information
Standard warranty applies.
Available Now
The Cirprotec Final Diverters SPD RS485 1 Pair is available now for immediate purchase. Ideal for surge protection in data networks.
Non-Returnable & Non-Cancellable
